74AUP1G125GW,125
Schmitt trigger 0.8V~3.6V 1 1 2.4ns@3.3V,5pF TSSOP-5-1.3mm Buffers, Drivers, Receivers, Transceivers RoHS
TSSOP-5-1.3mmROHS3 CompliantActive
Low-power buffer/line driver; 3-state
- Manufacturer
- Nexperia
- Manufacturer part #
- 74AUP1G125GW,125
- Store part #
- C478136
- Package / case
- TSSOP-5-1.3mm
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,745 in stock
#C478136
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹29.40 | ₹147.00 |
| 50+ | ₹23.36 | ₹1,168.00 |
| 150+ | ₹20.77 | ₹3,115.50 |
| 500+ | ₹17.56 | ₹8,780.00 |
| 3,000+ | ₹16.11 | ₹48,330.00 |
| 6,000+ | ₹15.25 | ₹91,500.00 |
5 × ₹29.40
₹147.00
excl. GST
₹173.46 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AUP1G125GW,125
₹147.00 for 5 + GST
Specifications
- Input type
- Schmitt trigger
- Voltage - Supply
- 0.8V~3.6V
- Output Type
- Tri-State
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 900nA
- Function
- Power-off isolation;Output enable
- Current - Output High(IOH)
- 4mA
- Series
- 74AUP
- Current - Output Low(IOL)
- 4mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Propagation Delay
- 2.4ns@3.3V,5pF
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.015 g
Overview
The 74AUP1G125 is a single buffer/line driver with 3-state output. Schmitt-trigger action at all inputs makes the circuit tolerant of slower input rise and fall times. This device ensures very low static and dynamic power consumption across the entire VCC range from 0.8 V to 3.6 V. This device is fully specified for partial power down applications using IOFF. The IOFF circuitry disables the output, preventing the potentially damaging backflow current through the device when it is powered down.
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| SN74AUP1G125DCKT#C2676046TI · SC-70-5 | TI | SC-70-5 | 20 | ₹40.81 · 20 in stock | View | |
| 74AUP1G240GW,125#C545816Nexperia · TSSOP-5-1.3mm | Nexperia | TSSOP-5-1.3mm | 2,335 | ₹12.49 · 2,335 in stock | View | |
 | 74AUP1G126GW,125#C554970Nexperia · TSSOP-5-1.3mm | Nexperia | TSSOP-5-1.3mm | 2,130 | ₹23.17 · 2,130 in stock | View |
 | SN74AUP1G240DCKR#C2652101TI · SC-70-5 | TI | SC-70-5 | 770 | ₹40.51 · 770 in stock | View |
 | 74AUP1G125SE-7#C842323DIODES · SOT-353 | DIODES | SOT-353 | 100 | ₹37.89 · 100 in stock | View |
