74HC04BQ,115
StandardCMOS 2V~6V 14ns@6V,50pF 2uA 6 DHVQFN-14-EP(2.5x3) Gates and Inverters RoHS
DHVQFN-14-EP(2.5x3)ROHS3 CompliantActive
Hex inverter
- Manufacturer
- Nexperia
- Manufacturer part #
- 74HC04BQ,115
- Store part #
- C546494
- Package / case
- DHVQFN-14-EP(2.5x3)
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,545 in stock
#C546494
Stock & price checked 25 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹26.54 | ₹132.70 |
| 50+ | ₹20.73 | ₹1,036.50 |
| 150+ | ₹18.23 | ₹2,734.50 |
| 500+ | ₹15.14 | ₹7,570.00 |
| 3,000+ | ₹13.75 | ₹41,250.00 |
| 6,000+ | ₹12.91 | ₹77,460.00 |
5 × ₹26.54
₹132.70
excl. GST
₹156.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74HC04BQ,115
₹132.70 for 5 + GST
Specifications
- output type
- Push-pull
- Logic Family
- 74HC
- Input Type
- StandardCMOS
- Voltage - Supply
- 2V~6V
- Output Logic Level - Low
- 100mV;400mV
- Propagation Delay
- 14ns@6V,50pF
- Operating Temperature
- -40℃~+125℃
- Input Logic Level - High
- 1.5V~4.2V
- Input Logic Level - Low
- 500mV~1.8V
- Output Logic Level - High
- 1.9V;3.84V;5.48V
- Quiescent Current(Iq)
- 2uA
- Number of Channels
- 6
- Current - Output High(IOH)
- 5.2mA
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.074 g
Overview
The 74HC04; 74HCT04 is a hex inverter. The inputs include clamp diodes that enable the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Applications
- Digital logic circuits
- Signal processing
- Voltage conversion
- Level shifting
- Current limiting
- Noise suppression
- Low-power applications
- High-temperature environments
- Wide voltage range applications
- CMOS and TTL compatible systems
- Electronic device protection
- ESD protection
- Data transmission
- Signal inversion
Key features
- Wide supply voltage range from 2.0 V to 6.0 V
- CMOS low power dissipation
- High noise immunity
- Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
- Complies with JEDEC standards:
- JESD8C (2.7 V to 3.6 V)
- JESD7A (2.0 V to 6.0 V)
- Input levels:
- For 74HC04: CMOS level
- For 74HCT04: TTL level
- ESD protection:
- HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V
- CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
- Multiple package options
- Specified from -40 ℃ to +85 ℃ and from -40 ℃ to +125 ℃
