74LVC2G07GW
Schmitt trigger 1.65V~5.5V 2 2.5ns@3.3V,50pF SOT-363 Buffers, Drivers, Receivers, Transceivers
SOT-363RoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74LVC2G07GW
- Store part #
- C52140489
- Package / case
- SOT-363
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,781 in stock
#C52140489
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹7.55 | ₹7.55 |
| 10+ | ₹5.95 | ₹59.50 |
| 30+ | ₹5.16 | ₹154.80 |
| 100+ | ₹4.55 | ₹455.00 |
| 500+ | ₹4.07 | ₹2,035.00 |
| 1,000+ | ₹3.84 | ₹3,840.00 |
1 × ₹7.55
₹7.55
excl. GST
₹8.91 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC2G07GW
₹7.55 for 1 + GST
Specifications
- Input type
- Schmitt trigger
- Voltage - Supply
- 1.65V~5.5V
- Output Type
- Open-drain
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 4uA
- Function
- Power-off isolation;Level shifting
- Series
- 74LVC
- Current - Output Low(IOL)
- 24mA
- Channel Type
- Unidirectional
- Number of Elements
- 2
- Propagation Delay
- 2.5ns@3.3V,50pF
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.074 g
Overview
The 74LVC2G07 is a dual buffer with open-drain outputs. Its inputs can be driven by 3.3V or 5V devices, enabling the device to be used as a level translator in mixed 3.3V and 5V environments. All inputs feature Schmitt-trigger action, making the circuit tolerant of slower input rise and fall times. The device is fully specified for partial power-down applications using I<sub>OFF</sub>. The I<sub>OFF</sub> circuit disables the outputs when the device is powered down, preventing harmful backflow current from flowing through the device.
Key features
- Wide supply voltage range: 1.65 V to 5.5 V
- Overvoltage-tolerant inputs up to 5.5 V
- High noise immunity
- CMOS low power consumption
- I<sub>OFF</sub> circuitry enables partial power-down mode operation
- High output drive capability: -24 mA (Vcc = 3.0 V)
- Latch-up performance exceeds 100 mA
- Direct TTL-level interface compatible
- Compliant with JEDEC standards: JESD8-7 (1.65 V to 1.95 V), JESD8-5 (2.3 V to 2.7 V), JESD8C (2.7 V to 3.6 V), JESD36 (4.5 V to 5.5 V)
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3B exceeds 8000 V, MM JESD22-A115C Class C exceeds 550 V, CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
- Multiple package options
- Buffer with open-drain output
