DIODES

74LVC2G126HD4-7

Schmitt trigger 1.65V~5.5V 2 1.9ns@5V,50pF DFN-8(1x2) Buffers, Drivers, Receivers, Transceivers RoHS

DFN-8(1x2)ROHS3 CompliantActive

Dual Buffer Gate with 3-State Outputs

Manufacturer: DIODES
Manufacturer part #: 74LVC2G126HD4-7
Store part #: C526351
Package / case: DFN-8(1x2)
Category: Buffers, Drivers, Receivers, Transceivers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,515 in stock

#C526351

Stock & price checked 2 days ago

Quantity	Unit price	Pack price
5+	₹14.62	₹73.10
50+	₹11.70	₹585.00
150+	₹10.24	₹1,536.00
500+	₹9.14	₹4,570.00
2,500+	₹8.27	₹20,675.00
5,000+	₹7.83	₹39,150.00

Quantity (min 5, multiples of 5)

5 × ₹14.62

₹73.10

excl. GST

₹86.26 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 5,000 per reel

74LVC2G126HD4-7

₹73.10 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Input type: Schmitt trigger
Voltage - Supply: 1.65V~5.5V
Output Type: Tri-State
Operating Temperature: -40℃~+125℃
Quiescent Supply Current: 10uA
Function: Power-off isolation;Output enable
Current - Output High(IOH): 32mA
Series: 74LVC
Current - Output Low(IOL): 32mA
Channel Type: Unidirectional
Number of Elements: 2
Propagation Delay: 1.9ns@5V,50pF

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 5,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.035 g

Overview

The 74LVC2G126 is a dual buffer gate with 3 - state outputs. The device is designed for operation over a power supply range of 1.65V to 5.5V. The device is fully specified for partial power down applications using IOFF. The IOFF circuitry disables the output, preventing damaging current backflow when the device is powered down.

Applications

Voltage Level Shifting
General Purpose Logic
Power Down Signal Isolation
PCs, Networking, Notebooks, Netbooks, PDAs
Tablet Computers, E - Readers
Computer Peripherals, Hard Drives, CD/DVD ROMs
TVs, DVDs, DVRs, Set Top Boxes
Cell Phones, Personal Navigation / GPS
MP3 Players, Cameras, Video Recorders

Key features

Wide Supply Voltage Range from 1.65 to 5.5V
±24mA Output Drive at 3.3V
CMOS Low Power Consumption
IOFF Supports Partial - Power - Down Mode Operation
Inputs accept up to 5.5V Schmitt Trigger Action at all inputs makes the circuit tolerant for slower input rise and fall times. The hysteresis is typically 100mV at VCC = 3.0V
ESD Protection Exceeds JESD 22 2000 - V Human Body Model (A114)
Exceeds 1000 - V Charged Device Model (C101)
Totally Lead - Free & Fully RoHS Compliant
Halogen and Antimony Free. “Green” Device
