Tokmas

ADA4522-1AR(TOKMAS)

32mA 1 100uV 15V/us 130dB 25pA 3.5MHz 1mA Rail-to-rail output SOT-23-5 Instrumentation, Op Amps, Buffer Amps

SOT-23-5RoHSActive

Manufacturer: Tokmas
Manufacturer part #: ADA4522-1AR(TOKMAS)
Store part #: C50338868
Package / case: SOT-23-5
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,701 in stock

#C50338868

Stock & price checked 2 days ago

Quantity	Unit price	Pack price
1+	₹44.56	₹44.56
10+	₹38.90	₹389.00
30+	₹36.29	₹1,088.70
100+	₹33.25	₹3,325.00
500+	₹31.95	₹15,975.00
1,000+	₹31.08	₹31,080.00

Quantity (min 1)

1 × ₹44.56

₹44.56

excl. GST

₹52.58 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

ADA4522-1AR(TOKMAS)

₹44.56 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Output Current: 32mA
Number of Channels: 1
Vos - Input Offset Voltage: 100uV
Slew Rate: 15V/us
Input Offset Current(Ios): 25pA
Operating Temperature: -40℃~+125℃
Common Mode Rejection Ratio(CMRR): 130dB
Ib - Input Bias Current: 25pA
Input Offset Voltage Drift(Vos TC): 2uV/℃
Gain Bandwidth Product: 3.5MHz
Quiescent Current: 1mA
Features: EMI filtering/RF suppression;ESD protection;Latch-up suppression
Input Voltage Noise Density: 30nV/√Hz@1kHz
Rail to Rail: Rail-to-rail output
Single Supply: 3V~36V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.042 g
