JSMSEMI
AT24C02C-SSHM-T
2Kbit 1MHz I2C SOP-8 Memory RoHS
SOP-8ROHS CompliantActive
2K-bit Serial EEPROM with Hardware Data Protection
Datasheet (PDF)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
43,100 in stock
#C22453058
Stock & price checked 20 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹7.03 | ₹70.30 |
| 100+ | ₹5.46 | ₹546.00 |
| 300+ | ₹4.68 | ₹1,404.00 |
| 1,000+ | ₹4.10 | ₹4,100.00 |
| 4,000+ | ₹4.05 | ₹16,200.00 |
| 8,000+ | ₹3.81 | ₹30,480.00 |
10 × ₹7.03
₹70.30
excl. GST
₹82.95 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
AT24C02C-SSHM-T
₹70.30 for 10 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Features
- Hardware write protection function;Noise suppression function
- Memory Size
- 2Kbit
- Voltage - Supply
- 1.7V~5.5V;0.28mA
- Clock Frequency
- 1MHz
- Access Time
- 0.55us
- Data Retention - TDR (Year)
- 100 Years
- Write Cycle Time(tWC)
- 3ms
- Standby Supply Current
- 0.5uA
- Write Cycle Endurance
- 1,000,000 cycles
- Interface
- I2C
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.182 g
Overview
The AT24C02C-SSHM-T/24C04/24C08/24C16 provides 2048/4096/8192/16384 bits of serial electrically erasable and programmable read-only memory (EEPROM), organized as 256/512/1024/2048 words of 8 bits each.
Key features
- Compatible with all I2C bidirectional data transfer protocol
- Memory array: - 2K bits (256X 8) / 4K bits (512 X 8) / 8K bits (1024 X 8) / 16K bits (2048x8) of EEPROM
- Page size: 16 bytes
- Single supply voltage and high speed: - 1 MHz Random and sequential Read modes
- Write: Byte Write within 3 ms
- Page Write within 3 ms Partial Page Writes Allowed
- Write Protect Pin for Hardware Data Protection
- Schmitt Trigger, Filtered Inputs for Noise Suppression
- High-reliability Endurance: 1 Million Write Cycles
- Data Retention: 100 Years
- Enhanced ESD/Latch-up protection HBM 8000V
- 8-lead PDIP/SOP/TSSOP/UDFN and WLCSP4 packages
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | JSM24C02#C2857178JSMSEMI · SOP-8 | JSMSEMI | SOP-8 | 3,740 | ₹7.69 · 3,740 in stock | View |
 | AT24C02D-SSHM-T#C22452050JSMSEMI · SOP-8 | JSMSEMI | SOP-8 | 49,330 | ₹7.61 · 49,330 in stock | View |
