ROHMDatasheet (PDF)
BU7266FVM-TR
2.4mA 2 1mV 2.4V/ms 1pA 60dB 700nA 4kHz Rail-to-Rail Input, Rail-to-Rail Output MSOP-8 Instrumentation, Op Amps, Buffer Amps RoHS
MSOP-8ROHS3 CompliantActive
Ultra Low Power CMOS Operational Amplifiers
- Manufacturer
- ROHM
- Manufacturer part #
- BU7266FVM-TR
- Store part #
- C2058287
- Package / case
- MSOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,001 in stock
#C2058287
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹70.90 | ₹70.90 |
| 10+ | ₹55.08 | ₹550.80 |
| 30+ | ₹48.36 | ₹1,450.80 |
| 100+ | ₹39.90 | ₹3,990.00 |
| 500+ | ₹36.00 | ₹18,000.00 |
| 1,000+ | ₹33.83 | ₹33,830.00 |
1 × ₹70.90
₹70.90
excl. GST
₹83.66 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
BU7266FVM-TR
₹70.90 for 1 + GST
Specifications
- Output Current
- 2.4mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 1mV
- Slew Rate
- 2.4V/ms
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+85℃
- Ib - Input Bias Current
- 1pA
- Common Mode Rejection Ratio(CMRR)
- 60dB
- Quiescent Current
- 700nA
- Gain Bandwidth Product
- 4kHz
- Rail to Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 1.8V~5.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.05 g
Overview
The BU7265G/BU7266xxx are ultra low supply current input output full swing CMOS operational amplifiers. The BU7265SG/BU7266Sxxx have an extended operating temperature range. They have low operating supply voltage and low input bias current. There are suitable for portable equipment and sensor amplifiers.
Applications
- Battery-powered Equipment
- Portable Equipment
- Consumer Equipment
- Sensor Amplifiers
Key features
- Ultra Low Supply Current
- Low Operating Supply Voltage
- Wide operating temperature Range (BU7265SG/BU7266Sxxx)
- Low Input Bias Current
