COS8051SOT
100mA 1 2mV 150V/us 2.5pA 125dB 2.6mA 175MHz Rail-to-Rail Input, Rail-to-Rail Output SOT23-5 Instrumentation, Op Amps, Buffer Amps RoHS
SOT23-5ROHS CompliantActive
175MHz Rail-to-Rail Input/Output High Speed Operational Amplifiers
- Manufacturer
- COSINE
- Manufacturer part #
- COS8051SOT
- Store part #
- C7463385
- Package / case
- SOT23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,175 in stock
#C7463385
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹37.19 | ₹185.95 |
| 50+ | ₹29.33 | ₹1,466.50 |
| 150+ | ₹25.96 | ₹3,894.00 |
| 500+ | ₹21.75 | ₹10,875.00 |
| 3,000+ | ₹19.87 | ₹59,610.00 |
| 6,000+ | ₹18.75 | ₹1,12,500.00 |
5 × ₹37.19
₹185.95
excl. GST
₹219.42 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
COS8051SOT
₹185.95 for 5 + GST
Specifications
- Output Current
- 100mA
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 2mV
- Slew Rate
- 150V/us
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 2.5pA
- Common Mode Rejection Ratio(CMRR)
- 125dB
- Input Offset Voltage Drift(Vos TC)
- 2uV/℃
- Quiescent Current
- 2.6mA
- Gain Bandwidth Product
- 175MHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 8nV/√Hz@1kHz
- Dual Supply
- -2.25V~2.25V
- Rail to Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 2.5V~5.5V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.047 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | COS8091SOT#C7463386COSINE · SOT23-5 | COSINE | SOT23-5 | 1,875 | ₹38.41 · 1,875 in stock | View |
