GN Semic

GN358A

Standard (General Purpose) Amplifier 2 Circuit SOP-8

SOP-8RoHSActive

A device composed of two independent high-gain operational amplifiers

Manufacturer: GN Semic
Manufacturer part #: GN358A
Store part #: C22461431
Package / case: SOP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,800 in stock

#C22461431

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
10+	₹9.35	₹93.50
100+	₹7.40	₹740.00
300+	₹6.42	₹1,926.00
1,000+	₹5.68	₹5,680.00
4,000+	₹5.09	₹20,360.00
8,000+	₹4.80	₹38,400.00

Quantity (min 10, multiples of 10)

10 × ₹9.35

₹93.50

excl. GST

₹110.33 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

GN358A

₹93.50 for 10 + GST

Specifications

Output Current: 40mA
Number of Channels: 2
Vos - Input Offset Voltage: 1.5mV
Input Offset Current(Ios): 50nA
Operating Temperature: -25℃~+85℃
Ib - Input Bias Current: 45nA
Common Mode Rejection Ratio(CMRR): 90dB
Quiescent Current: 2mA
Dual Supply: -12V~-2V;2V~12V
Single Supply: 4V~24V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.178 g

Overview

GN358A consists of two independent high-gain operational amplifiers. It supports both single-supply and dual-supply operation, with supply current independent of supply voltage. Applications include audio amplifiers, industrial control, DC gain components, and all conventional op-amp circuits.
