UMW
XC6206P332MRLinear Voltage Regulator IC Positive Fixed 1 Output 250mA SOT-23
From
₹2.53
18,64,100 in stock
GRDatasheet (PDF)
GR6206P332MR-G
Linear Voltage Regulator IC Positive Fixed 1 Output 200mA SOT-23-3
SOT-23-3RoHSActive
IC REG LINEAR 3.3V 200mA SOT-23-3
- Manufacturer
- GR
- Manufacturer part #
- GR6206P332MR-G
- Store part #
- C19631737
- Package / case
- SOT-23-3
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
10,100 in stock
#C19631737
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 50+ | ₹1.83 | ₹91.50 |
| 500+ | ₹1.42 | ₹710.00 |
| 3,000+ | ₹1.19 | ₹3,570.00 |
| 6,000+ | ₹1.06 | ₹6,360.00 |
| 24,000+ | ₹0.9393 | ₹22,543.20 |
| 51,000+ | ₹0.8732 | ₹44,533.20 |
50 × ₹1.83
₹91.50
excl. GST
₹107.97 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
GR6206P332MR-G
₹91.50 for 50 + GST
Specifications
- Output Voltage
- 3.3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃
- Supply Current (Iq)
- 6.5uA
- Output Configuration
- Positive
- Output Current
- 200mA
- Operating Voltage
- 6.5V
- Features
- Over Current Protection;Short Circuit Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 50 (multiples of 50)
- Unit weight
- 0.037 g
Overview
The GR6206xx series are CMOS step-down voltage regulators with high ripple rejection, low quiescent current, low dropout, and overcurrent/short-circuit protection. These devices feature an ultra-low quiescent current (6.5μA Typ.), capable of delivering 200mA output current with minimal input-to-output voltage differential while maintaining excellent regulation. The combination of low dropout voltage and low quiescent current makes these devices ideal for battery-powered applications requiring extended battery life, such as computers, consumer electronics, and industrial equipment.
Applications
- Battery-powered systems
- Portable consumer devices
- Cordless telephone equipment
- Portable instrumentation
- Wireless control systems
- Automotive electronics
- Portable/handheld computers
- Voltage reference sources
Key features
- High-accuracy output voltage: ±2.5%
- Maximum input voltage up to 6.5V
- Output voltage: 1.5V~5.0V (step 0.1V)
- Usable as both regulator and voltage reference
- Ultra-low quiescent current (Typ. = 6.5 μA)
- Package: SOT89-3, SOT23-3
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | GR6206P332MR#C19631745GR · SOT-23-3 | GR | SOT-23-3 | 50 | ₹2.70 · 50 in stock | View |
 | HT7533ST#C49191520GR · SOT-23-3 | GR | SOT-23-3 | 7,540 | ₹4.46 · 7,540 in stock | View |
 | GR5300A33M3G#C19631801GR · SOT-23 | GR | SOT-23 | 1,600 | ₹4.33 · 1,600 in stock | View |
 | GR7333#C19631787GR · SOT-23 | GR | SOT-23 | 2,330 | ₹5.52 · 2,330 in stock | View |
