HGSEMI

HGOP07DM/TR

Standard (General Purpose) Amplifier 1 Circuit SOP-8

SOP-8RoHSActive

Low Offset Single Operational Amplifier

Manufacturer: HGSEMI
Manufacturer part #: HGOP07DM/TR
Store part #: C22446762
Package / case: SOP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,360 in stock

#C22446762

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹21.58	₹107.90
50+	₹16.95	₹847.50
150+	₹14.96	₹2,244.00
500+	₹12.49	₹6,245.00
2,500+	₹11.38	₹28,450.00
5,000+	₹10.72	₹53,600.00

Quantity (min 5, multiples of 5)

5 × ₹21.58

₹107.90

excl. GST

₹127.32 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 2,500 per reel

HGOP07DM/TR

₹107.90 for 5 + GST

Specifications

Number of Channels: 1
Vos - Input Offset Voltage: 150uV
Input Offset Current(Ios): 8nA
Operating Temperature: 0℃~+70℃
Ib - Input Bias Current: 28nA
Common Mode Rejection Ratio(CMRR): 100dB
Input Offset Voltage Drift(Vos TC): 1.8uV/℃
Quiescent Current: 3.8mA
Gain Bandwidth Product: 500kHz
Dual Supply: -18V~-3V;3V~18V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.26 g

Overview

HGOP07 is a high-precision op-amp with a maximum offset voltage of 150μV and a gain of 200V/mV. It is therefore particularly well suited for instrumentation applications. The HGOP07 features a wide input voltage range (±13V) and a CMRR of over 100dB, while maintaining excellent linearity and gain accuracy in high closed-loop gain circuits.
