HT2171ARZ

- The SC8631/1A/2 are CMOS op-amps with low offset, stable high frequency response, low power, low supply voltage, and rail-to-rail inputs and outputs. SC8631/1A/2 have a high gain-bandwidth product of 6MHz, 3.7V/µs slew rate while consuming only 480µA of supply current per amplifier. The maximum input offset voltage is 3mV for SC8631/1A/2. Beyond the rail input and rail-to-rail output characteristics allow the full power-supply voltage to be used for signal range. The operating range is from 2.5V to 5.5V. This combination of features makes the SC8631/1A/2 superior among rail-to-rail input/output CMOS op amps in its power class. It is specified over the extended industrial temperature rang -40℃ to +125℃. The SC8631/1A/2 can be used as cost-effective plug-in replacements for many commercially available op amps to reduce power and improve input/output range and performance. - The HT2171A are CMOS op-amps with low offset, stable high frequency response, low power, low supply voltage, and rail-to-rail inputs and outputs. Stable 6MHz GBWP with Low l₀ of Only 330µA Typical per Amplifier. Offset Voltage: ±500µV Maximum. High Slew Rate: 3.7V/µs. Input Bias Current: 1pA Typical. CMRR/PSRR: 100dB/100dB. Settling time to 0.1% with 2V Step: 0.46us. Beyond the Rails Input Common-Mode Range. Output Swing to within ±10mV Typical of each Rail. No Phase Reversal for Overdriven Inputs. Supply Voltage Range: 2.5V to 5.5V. -40°C to 125°C Operation Range. Green, Popular Type Package. HT2171A have a high gain-bandwidth product of 6MHz, 3.7V/µs slew rate while consuming only 330µA of supply current per amplifier. The maximum input offset voltage is 500µV for HT2171A. Beyond the rail input and rail-to-rail output characteristics allow the full power-supply voltage to be used for signal range. The operating range is from 2.5V to 5.5V. This combination of features makes the HT2171A superior among rail-to-rail input/output CMOS op amps in its power class. It is specified over the extended industrial temperature rang -40°C to 125°C. The HT2171A can be used as cost-effective plug-in replacements for many commercially available op amps to reduce power and improve input/output range and performance.

Applications

• Active Filters, ASIC Input or Output Amplifier
• Sensor Interface
• Smoke/Gas/Environment Sensors
• Portable Instruments and Mobile Device
• Audio Output
• PCMCIA Cards
• Battery or Solar Power Systems
• Medical Equipment
• Piezo Electrical Transducer Amplifier
