HYCONDatasheet (PDF)
HY2212-BB3A
Battery Balancing IC LiFePO4 Battery SOT-23-6
SOT-23-6RoHSActive
1-cell Lithium Iron Phosphate (LiFePO4) Battery Charging Balancing IC
- Manufacturer
- HYCON
- Manufacturer part #
- HY2212-BB3A
- Store part #
- C782017
- Package / case
- SOT-23-6
- Category
- Battery Management
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
5,570 in stock
#C782017
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹15.25 | ₹76.25 |
| 50+ | ₹12.03 | ₹601.50 |
| 150+ | ₹10.41 | ₹1,561.50 |
| 500+ | ₹9.21 | ₹4,605.00 |
| 3,000+ | ₹8.23 | ₹24,690.00 |
| 6,000+ | ₹7.75 | ₹46,500.00 |
5 × ₹15.25
₹76.25
excl. GST
₹89.98 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
HY2212-BB3A
₹76.25 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Quiescent Current
- 500nA
- 0V Battery Charge
- Not supported
- Type of Battery
- LiFePO4 Battery
- Operating Voltage
- 1.5V~8V
- Features
- Cell balancing
- The Chip Type
- Balancing IC
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.047 g
Overview
The HY2212 series IC integrates a high-precision voltage detection circuit and delay circuit, designed as a cell-level monitoring chip for charge balancing control of individual lithium-ion cells in multi-cell battery packs.
Applications
- Multi-cell LiFePO₄ rechargeable battery pack
Key features
- High-precision voltage detection circuit
- Overcharge detection voltage 3.200~4.000V, accuracy ±25mV
- Overcharge release voltage 3.000~4.000V, accuracy ±35mV
- Standby detection voltage 2.70V, accuracy ±15%
- Standby release voltage 2.70V, accuracy ±15%
- Overcharge delay time set by internal circuit (no external capacitor)
- Low supply current
- Operating mode: typical 2.5μA, maximum 3.5μA (VDD = 3.2V)
- Standby mode: maximum 0.5μA (VDD = 2.0V)
- Wide operating temperature range: -40°C~+85°C
- Compact package: SOT-23-6
- Halogen-free, RoHS-compliant product
