MSKSEMIDatasheet (PDF)
JRC4558
Standard (General Purpose) Amplifier 2 Circuit SOP-8
SOP-8RoHSActive
Dual low-power differential operational amplifier
- Manufacturer
- MSKSEMI
- Manufacturer part #
- JRC4558
- Store part #
- C5252906
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
23,340 in stock
#C5252906
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹4.93 | ₹98.60 |
| 200+ | ₹3.89 | ₹778.00 |
| 600+ | ₹3.29 | ₹1,974.00 |
| 2,500+ | ₹2.80 | ₹7,000.00 |
| 10,000+ | ₹2.50 | ₹25,000.00 |
| 20,000+ | ₹2.33 | ₹46,600.00 |
20 × ₹4.93
₹98.60
excl. GST
₹116.35 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
JRC4558
₹98.60 for 20 + GST
Specifications
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 5mV
- Input Offset Current(Ios)
- 10nA
- Operating Temperature
- 0℃~+70℃
- Common Mode Rejection Ratio(CMRR)
- 80dB
- Ib - Input Bias Current
- 250nA
- Quiescent Current
- 500uA
- Gain Bandwidth Product
- 1.2MHz
- Features
- Built-in compensation
- Dual Supply
- -15V~15V
- Single Supply
- 3V~30V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.167 g
Overview
The JRC4558 is a dual low-power differential operational amplifier capable of operating from either single or dual power supplies. It features high open-loop gain, internal compensation, wide common-mode range, excellent temperature stability, and output short-circuit protection. Widely used in audio amplifier circuits and conventional op-amp circuit applications.
Applications
- Sensor signal amplifier
- Audio amplifier
- DC gain
Key features
- Internal frequency compensation
- Single supply voltage range: 3V~30V
- Short-circuit protection
- Dual supply voltage range: ±15V
- Low power consumption: typical 500uA @ VCC=5V
- Unity gain bandwidth: up to 1.2MHz
- Package: DIP8, SOP8
