COSINEDatasheet (PDF)
LM2904SR
Standard (General Purpose) Amplifier 2 Circuit SOP-8
SOP-8ROHS CompliantActive
Low-cost, high-voltage operational amplifiers
- Manufacturer
- COSINE
- Manufacturer part #
- LM2904SR
- Store part #
- C42437069
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,850 in stock
#C42437069
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹8.04 | ₹80.40 |
| 100+ | ₹6.27 | ₹627.00 |
| 300+ | ₹5.38 | ₹1,614.00 |
| 1,000+ | ₹4.72 | ₹4,720.00 |
| 4,000+ | ₹4.19 | ₹16,760.00 |
| 8,000+ | ₹3.93 | ₹31,440.00 |
10 × ₹8.04
₹80.40
excl. GST
₹94.87 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
LM2904SR
₹80.40 for 10 + GST
Specifications
- Output Current
- 20mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 2mV
- Slew Rate
- 350V/ms
- Input Offset Current(Ios)
- 3nA
- Operating Temperature
- -40℃~+85℃
- Common Mode Rejection Ratio(CMRR)
- 90dB
- Ib - Input Bias Current
- 45nA
- Input Offset Voltage Drift(Vos TC)
- 7uV/℃
- Gain Bandwidth Product
- 1MHz
- Quiescent Current
- 250uA
- Features
- Built-in compensation
- Dual Supply
- -18V~18V
- Single Supply
- 3V~36V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.257 g
Overview
The LM2904 (dual) and LM2902 (quad) are low-power, low cost operational amplifiers (op amps) operated on 3V to 36V supplies. Despite their wide supply range, the LM2904/2902 family provides excellent overall performance and versatility. They have high differential input voltage capability. The common-mode input voltage range includes ground, enabling direct sensing near ground. The LM2904/2902 family is unity gain stable and has a gain bandwidth product of 1.0MHz (typical). They provide high CMRR and PSRR performance and can operate from a single supply voltage as well as dual supply voltages. The LM2904/2902 family can be designed into a wide range of applications at an economical price without sacrificing basic performance.
Applications
- Power Supplies and Mobile Chargers
- Motor Control
- AC Inverters
- White Goods
- Battery or Solar Powered Systems
Key features
- Wide Supply Range of 3V ~ 36V
- Large DC Voltage Gain: 100dB
- Quiescent Current per Amplifier: 250μA
- Gain Bandwidth Product: 1.0 MHz
- Slew Rate: 0.35V/µs
- Unity Gain Stable
- Input Common-mode Voltage Range Includes negative Rails
- Differential Input Voltage Range Equal to the Power Supply Voltage
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM358SR#C5183766COSINE · SOP-8 | COSINE | SOP-8 | 2,440 | ₹10.95 · 2,440 in stock | View |
 | COS2170SRA#C7434389COSINE · SOP-8 | COSINE | SOP-8 | 603 | ₹55.69 · 603 in stock | View |
 | COS2170SRB#C7434390COSINE · SOP-8 | COSINE | SOP-8 | 361 | ₹52.38 · 361 in stock | View |
 | COS822SR#C693067COSINE · SOIC-8 | COSINE | SOIC-8 | 1,010 | ₹19.90 · 1,010 in stock | View |
 | COS6002SR#C693060COSINE · SOIC-8 | COSINE | SOIC-8 | 10,845 | ₹14.42 · 10,845 in stock | View |
