TIDatasheet (PDF)
LM9036QM-5.0/NOPB
5V Positive Fixed SOIC-8 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
SOIC-8ROHS3 CompliantActive
Automotive 50mA, battery-operated operation (40V), low IQ, low-dropout regulator
- Manufacturer
- TI
- Manufacturer part #
- LM9036QM-5.0/NOPB
- Store part #
- C2878337
- Package / case
- SOIC-8
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
75 in stock
#C2878337
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹187.65 | ₹187.65 |
| 10+ | ₹155.77 | ₹1,557.70 |
| 30+ | ₹138.35 | ₹4,150.50 |
| 100+ | ₹118.81 | ₹11,881.00 |
| 500+ | ₹109.88 | ₹54,940.00 |
| 1,000+ | ₹106.05 | ₹1,06,050.00 |
1 × ₹187.65
₹187.65
excl. GST
₹221.43 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 95 per tube
LM9036QM-5.0/NOPB
₹187.65 for 1 + GST
Specifications
- Output Voltage
- 5V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+125℃@(Ta)
- Supply Current (Iq)
- 25uA
- Output Configuration
- Positive
- Operating Voltage
- 40V
- Output Current
- 50mA
- Features
- Short Circuit Protection;Thermal shutdown;Reverse polarity voltage protection;Over Current Protection
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 95 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.269 g
Overview
The LM9036Q ultra-low quiescent current regulator features low dropout voltage and low current in the standby mode. With less than 25μA Ground Pin current at a 0.1 mA load, the LM9036Q is ideally suited for automotive and other battery operated systems. The LM9036Q retains all of the features that are common to low dropout regulators including a low dropout PNP pass device, short circuit protection, reverse battery protection, and thermal shutdown. The LM9036Q has a 40V maximum operating voltage limit, a -40℃ to +125℃ operating temperature range, and ±5% output voltage tolerance over the entire output current, input voltage, and temperature range.
Applications
- Automotive systems
- Battery-powered systems
Key features
- AEC-Q100 Grade 1 Qualified (-40°C to 125°C)
- Ultra Low Ground Pin Current (I_GND ≤ 25μA for I_out = 0.1 mA)
- Fixed 5V, 3.3V, 50mA Output
- Output Tolerance ±5% Over Line, Load, and Temperature
- Dropout Voltage Typically 200mV @ I_out = 50mA
- -45V Reverse Transient Protection
- Internal Short Circuit Current Limit
- Internal Thermal Shutdown Protection
- 40V Operating Voltage Limit
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | LM9036MX-5.0/NOPB#C2871916TI · SOIC-8 | TI | SOIC-8 | 1,070 | ₹85.43 · 1,070 in stock | View |
 | LM2936QHBMAX5.0/NOPB#C2872051TI · SOIC-8 | TI | SOIC-8 | 6 | ₹367.41 · 6 in stock | View |
 | LM2936QM-5.0/NOPB#C2878267TI · SOIC-8 | TI | SOIC-8 | 10 | ₹464.19 · 10 in stock | View |
 | LM2936BM-5.0/NOPB#C2878295TI · SOIC-8 | TI | SOIC-8 | 10 | ₹412.30 · 10 in stock | View |
 | LM2936QMX-5.0/NOPB#C2878298TI · SOIC-8 | TI | SOIC-8 | 10 | ₹488.39 · 10 in stock | View |
