LinearinDatasheet (PDF)
LTA4584XS14/R5
4 3mV 17V/us 100pA 110dB 7.3mA 19MHz Rail-to-rail output SOIC-14L Instrumentation, Op Amps, Buffer Amps RoHS
SOIC-14LROHS CompliantActive
Low Noise Audio Operational Amplifiers
- Manufacturer
- Linearin
- Manufacturer part #
- LTA4584XS14/R5
- Store part #
- C5445099
- Package / case
- SOIC-14L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,197 in stock
#C5445099
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹68.87 | ₹68.87 |
| 10+ | ₹60.61 | ₹606.10 |
| 30+ | ₹56.47 | ₹1,694.10 |
| 100+ | ₹52.51 | ₹5,251.00 |
| 500+ | ₹49.93 | ₹24,965.00 |
| 1,000+ | ₹48.73 | ₹48,730.00 |
1 × ₹68.87
₹68.87
excl. GST
₹81.27 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
LTA4584XS14/R5
₹68.87 for 1 + GST
Specifications
- Number of Channels
- 4
- Vos - Input Offset Voltage
- 3mV
- Slew Rate
- 17V/us
- Input Offset Current(Ios)
- 100pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 100pA
- Common Mode Rejection Ratio(CMRR)
- 110dB
- Input Offset Voltage Drift(Vos TC)
- 2uV/℃
- Quiescent Current
- 7.3mA
- Gain Bandwidth Product
- 19MHz
- Dual Supply
- 2V~36V
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 4V~36V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.26 g
Overview
The LTA4580 device is a dual operational amplifier that has been designed optimally for audio applications, such as improving tone control. The LTA4580 device offers low noise, high gain bandwidth, low harmonic distortion, and high output current, all of which make the device ideally suited for audio electronics, such as preamplifiers, active filters, and professional audio mixers. When high output current is required, this device can be used as a headphone amplifier. The LTA4580 device is improved to rail-to-rail output swing and an input common mode range that includes the -Vₛ rail. Due to its wide operating supply voltage, this device can also be used in low-voltage applications. The LTA4584 device is an additional supply of quad audio operational amplifier that features same performance. This device offers in 14-pin industry-standard configuration for obtaining the space and cost savings.
Applications
- Audio Preamplifiers
- Active Filters
- Pro Audio Mixers
- Headphone Amplifiers
- Netbooks
- Multichannel Video Transcoders
- Industrial Measurement Equipment
Key features
- Wide Supply: ±2 V to ±18 V, 4 V to 36 V
- Wide Bandwidth: 19 MHz GBW
- High Slew Rate: 17 V/μs
- Low Noise Voltage: 0.8 μVᵣₘₛ
- Total Harmonic Distortion: 0.0005%
- Low Offset Voltage: ±3 mV
- Maximum Input Common Mode Range: -Vₛ to +Vₛ - 2 V
- Rail-to-Rail Output Swing
- Drop-In Replacement for NJM4580, NE5532, RC4580, NJM4560/2/5, and LM833
- Additional Quad in 14-Pin Industry-Standard: LTA4584
