MICROCHIPDatasheet (PDF)
MCP606T-I/OT
17mA 1 250uV 80V/ms 91dB 80pA 155kHz 18.7uA Rail-to-rail output SOT-23-5 Instrumentation, Op Amps, Buffer Amps RoHS
SOT-23-5ROHS3 CompliantActive
Micropower CMOS Op Amps
- Manufacturer
- MICROCHIP
- Manufacturer part #
- MCP606T-I/OT
- Store part #
- C91380
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,122 in stock
#C91380
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹130.58 | ₹130.58 |
| 10+ | ₹110.15 | ₹1,101.50 |
| 30+ | ₹99.94 | ₹2,998.20 |
| 100+ | ₹89.73 | ₹8,973.00 |
| 500+ | ₹83.65 | ₹41,825.00 |
| 1,000+ | ₹80.61 | ₹80,610.00 |
1 × ₹130.58
₹130.58
excl. GST
₹154.08 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MCP606T-I/OT
₹130.58 for 1 + GST
Specifications
- Output Current
- 17mA
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 250uV
- Slew Rate
- 80V/ms
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+85℃
- Common Mode Rejection Ratio(CMRR)
- 91dB
- Ib - Input Bias Current
- 80pA
- Input Offset Voltage Drift(Vos TC)
- 1.8uV/℃
- Gain Bandwidth Product
- 155kHz
- Quiescent Current
- 18.7uA
- Features
- Built-in compensation;ESD protection
- Input Voltage Noise Density
- 38nV/√Hz@1kHz
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 2.5V~5.5V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.043 g
Overview
The MCP606, MCP607, MCP608 and MCP609 are unity gain stable, low offset voltage operational amplifiers capable of precision low power single supply operation. Performance characteristics include ultra low offset voltage (250 μv max.), rail-to-rail output swing capability, and low input bias current (80 pA@85°C). These features make this family of amplifiers well suited for single supply precision, high impedance, battery powered applications.
Applications
- Battery Power Instruments
- High Impedance Applications - Photodiode Pre-amps - pH probe Buffer Amplifier - Infrared Detectors - Precision Integrators Charge Amplifier for Piezoelectric Transducers
- Strain Gauges
- Medical Instruments
- Test Equipment
Key features
- Low Power IDD = 25 μA, max
- Low Offset Voltage: 250 μV, max
- Rail-to-Rail Swing at Output
- 80 pA Low Input Bias Current over Temperature
- Unity Gain Stable
- Chip Select (CS) Capability with MCP608
- Industrial Temperature range supported
- No Phase Reversal
- Available in Single, Dual, and Quad
