MICRONE

ME358ASG

Standard (General Purpose) Amplifier 2 Circuit Rail-to-Rail Input, Rail-to-Rail Output SOP-8

SOP-8RoHSActive

Rail-to-rail I/O, low-power operational amplifier

Manufacturer: MICRONE
Manufacturer part #: ME358ASG
Store part #: C487901
Package / case: SOP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

4,860 in stock

#C487901

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹16.11	₹80.55
50+	₹12.54	₹627.00
150+	₹10.77	₹1,615.50
500+	₹9.43	₹4,715.00
3,000+	₹8.36	₹25,080.00
6,000+	₹7.83	₹46,980.00

Quantity (min 5, multiples of 5)

5 × ₹16.11

₹80.55

excl. GST

₹95.05 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

ME358ASG

₹80.55 for 5 + GST

Specifications

Output Current: 85mA
Number of Channels: 2
Vos - Input Offset Voltage: 800uV
Slew Rate: 580V/ms
Input Offset Current(Ios): 1pA
Operating Temperature: -40℃~+85℃
Ib - Input Bias Current: 10pA
Common Mode Rejection Ratio(CMRR): 86dB
Input Offset Voltage Drift(Vos TC): 2uV/℃
Quiescent Current: 90uA
Gain Bandwidth Product: 1MHz
Input Voltage Noise Density: 27nV/√Hz@1kHz
Dual Supply: -2.75V~-1.05V;1.05V~2.75V
Rail to Rail: Rail-to-Rail Input, Rail-to-Rail Output
Single Supply: 2.1V~5.5V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.195 g

Overview

ME358 is a rail-to-rail input/output voltage feedback op-amp with wide input common-mode range and output swing. The minimum supply voltage is as low as 2.1V, with a maximum of 5.5V, and the operating temperature range is -40℃~85℃. The ME358 dual-channel quiescent current is only 90uA, while providing 1MHz unity-gain bandwidth. The input offset current is only 10pA, making ME358 widely applicable in integrators, photodiodes, piezoresistive sensors, and other fields. Rail-to-rail I/O offers great convenience for system engineers' designs. Low quiescent current is suitable for battery-powered, low-power system environments.
