NC7SP86P5X-TP

500nA 800mV~3.6V 2.3ns@3.3V,5pF SOT-353 Gates and Inverters

SOT-353RoHSActive

Manufacturer: TECH PUBLIC
Manufacturer part #: NC7SP86P5X-TP
Store part #: C52098157
Package / case: SOT-353
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,000 in stock

#C52098157

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
10+	₹8.55	₹85.50
100+	₹6.73	₹673.00
300+	₹5.81	₹1,743.00
3,000+	₹5.13	₹15,390.00
6,000+	₹4.58	₹27,480.00
9,000+	₹4.31	₹38,790.00

Quantity (min 10, multiples of 10)

10 × ₹8.55

₹85.50

excl. GST

₹100.89 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 3,000 per reel

NC7SP86P5X-TP

₹85.50 for 10 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Input Logic Level - Low: 700mV;900mV
Operating Temperature: -40℃~+125℃
Input Logic Level - High: 1.6V;2V
Features: Local shutdown mode
Output Logic Level - High: 1.11V;1.32V;2.05V;1.9V;2.72V;2.6V
Quiescent Current(Iq): 500nA
Voltage - Supply: 800mV~3.6V
Number of Channels: 1;2
Propagation Delay: 2.3ns@3.3V,5pF
Output Logic Level - Low: 310mV;440mV

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.029 g

Overview

This device is a single 2-input XOR gate that implements the function Y = A XOR B or Y = A'B + AB' in positive logic. The device ensures ultralow static and dynamic power consumption across the entire VCC range of 0.8V to 3.6V.

Applications

AV receiver
Audio dock
Blu-ray player & home theater
Embedded PC
Personal digital assistant

Key features

Wide supply voltage range: 0.8V to 3.6V
Inputs accept voltages up to 3.6V
I<sub>OFF</sub> supports partial power-down mode
Low quiescent power consumption; I<sub>CC</sub> = 0.5μA (maximum)
ESD protection exceeds JESD 22: -2000-V HBM (A114-A), -200-V MM (A115-A), -1000-V CDM (C101)

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	NC7SV86P5X-TP#C54561876TECH PUBLIC · SOT-353	TECH PUBLIC	SOT-353	2,930	₹21.86 · 2,930 in stock	View
	74AUP1G86GW-TP#C48995440TECH PUBLIC · SOT-353	TECH PUBLIC	SOT-353	On request	₹8.16 · 0 in stock	View
