NCP170ASN300T2G
3V Positive Fixed TSOP-5 Voltage Regulators - Linear, Low Drop Out (LDO) Regulators RoHS
TSOP-5ROHS3 CompliantActive
LDO Regulator Ultra-Low IQ, CMos 150 mA
- Manufacturer
- onsemi
- Manufacturer part #
- NCP170ASN300T2G
- Store part #
- C603670
- Package / case
- TSOP-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,846 in stock
#C603670
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹56.81 | ₹56.81 |
| 10+ | ₹45.10 | ₹451.00 |
| 30+ | ₹40.11 | ₹1,203.30 |
| 100+ | ₹34.04 | ₹3,404.00 |
| 500+ | ₹27.11 | ₹13,555.00 |
| 1,000+ | ₹25.38 | ₹25,380.00 |
1 × ₹56.81
₹56.81
excl. GST
₹67.04 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
NCP170ASN300T2G
₹56.81 for 1 + GST
Specifications
- Output Voltage
- 3V
- Number of Outputs
- 1
- Operating Temperature
- -40℃~+85℃@(Tj)
- Output Configuration
- Positive
- Operating Voltage
- 5.5V
- Output Current
- 150mA
- Features
- Enable control;Over Current Protection;Thermal shutdown;Output discharge
- Output Type
- Fixed
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.036 g
Overview
The NCP170 series of CMOS low dropout regulators are designed specifically for portable battery-powered applications which require ultra-low quiescent current. The ultra-low consumption of typ. 500 nA ensures long battery life and dynamic transient boost feature improves device transient response for wireless communication applications. The device is available in small 1×1 mm XDFN4, SOT-563 and TSOP-5 packages.
Applications
- Battery Powered Equipments
- Portable Communication Equipments
- Cameras, Image Sensors and Camcorders
Key features
- Operating Input Voltage Range: 2.2 V to 5.5 V
- Output Voltage Range: 1.2 V to 3.6 V (0.1 V Steps)
- Ultra-Low Quiescent Current Typ. 0.5 μA
- Low Dropout: 170 mV Typ. at 150 mA
- High Output Voltage Accuracy ±1%
- Stable with Ceramic Capacitors 1 μF
- Over-Current Protection
- Thermal Shutdown Protection
- NCP170A for Active Discharge Option
- Available in Small 1×1 mm XDFN4, SOT−563 and TSOP-5 Packages
- These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TLV73330PDBVT#C2866067TI · SOT-23-5 | TI | SOT-23-5 | 655 | ₹72.20 · 655 in stock | View |
 | TLV73330PDBVR#C882826TI · SOT-23-5 | TI | SOT-23-5 | 995 | ₹17.87 · 995 in stock | View |
 | TLV73330PQDBVRQ1#C2864359TI · SOT-23-5 | TI | SOT-23-5 | 80 | ₹20.72 · 80 in stock | View |
 | JY1103-H300BX#C3038103JingYang · SOT-23-5L | JingYang | SOT-23-5L | 1,825 | ₹15.19 · 1,825 in stock | View |
 | XC6210B302MR#C23378034TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 3,140 | ₹21.66 · 3,140 in stock | View |
