RICHTEKDatasheet (PDF)
RT9146ZQW
1A 1 15mV 35V/us 95dB 50nA 4mA 12MHz Rail-to-Rail Input, Rail-to-Rail Output WDFN-8(3x3) Instrumentation, Op Amps, Buffer Amps RoHS
WDFN-8(3x3)ROHS3 CompliantActive
Rail-to-Rail Operational Amplifier
- Manufacturer
- RICHTEK
- Manufacturer part #
- RT9146ZQW
- Store part #
- C6288623
- Package / case
- WDFN-8(3x3)
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,005 in stock
#C6288623
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹56.86 | ₹284.30 |
| 50+ | ₹46.48 | ₹2,324.00 |
| 150+ | ₹42.03 | ₹6,304.50 |
| 1,500+ | ₹36.49 | ₹54,735.00 |
| 3,000+ | ₹34.01 | ₹1,02,030.00 |
| 4,500+ | ₹32.53 | ₹1,46,385.00 |
5 × ₹56.86
₹284.30
excl. GST
₹335.47 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 1,500 per reel
RT9146ZQW
₹284.30 for 5 + GST
Specifications
- Output Current
- 1A
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 15mV
- Slew Rate
- 35V/us
- Operating Temperature
- -40℃~+85℃
- Common Mode Rejection Ratio(CMRR)
- 95dB
- Ib - Input Bias Current
- 50nA
- Quiescent Current
- 4mA
- Gain Bandwidth Product
- 12MHz
- Features
- Built-in compensation
- Rail to Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 6V~20V
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 1,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.127 g
Overview
The RT9146/7 consists of a low power, high slew rate, single supply rail-to-rail input and output operational amplifier. The RT9146 contains a single amplifier and the RT9147 contains two amplifiers in one package. The RT9146/7 has a high slew rate (35V/μs), 1A peak output current and offset voltage below 15mV. The RT9146/7 is ideal for Thin Film Transistor Liquid Crystal Displays (TFT-LCD). The RT9146 is available in the WDFN-8L 3x3 package, and the RT9147 is available in the WQFN-16L 4x4 package. The RT9146/7 are specified for operation over the full -40°C to 85°C temperature range.
Applications
- TFT-LCD Panels
- Notebook Computers
- Monitors
- LCD TVs
Key features
- Rail-to-Rail Output Swing
- Supply Voltage: 6V to 20V
- Peak Output Current: 1A
- High Slew Rate: 35V/μs
- Unity Gain Stable
- RoHS Compliant and Halogen Free
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| LT1010CDD#PBF#C579596ADI · DFN-8-EP(3x3) | ADI | DFN-8-EP(3x3) | 1 | ₹1,305.09 · 1 in stock | View | |
 | OPA817DTKR#C18236257TI · WSON-8-EP(3x3) | TI | WSON-8-EP(3x3) | 22 | ₹1,311.73 · 22 in stock | View |
| THS4275DRBT#C2867698TI · VSON-8-EP(3x3) | TI | VSON-8-EP(3x3) | On request | Price on request | Quote | |
| THS4271DRBT#C2878079TI · SON-8(3x3) | TI | SON-8(3x3) | On request | Price on request | Quote | |
| THS4215DRBT#C1880153TI · VSON-8-EP(3x3) | TI | VSON-8-EP(3x3) | On request | Price on request | Quote | |
