SN74AHC125PWR
2V~5.5V 1 4 5.3ns@5V,50pF TSSOP-14 Buffers, Drivers, Receivers, Transceivers RoHS
TSSOP-14ROHS3 CompliantActive
QUADRUPLE 2-INPUT POSITIVE-NAND GATES
- Manufacturer
- TI
- Manufacturer part #
- SN74AHC125PWR
- Store part #
- C54529
- Package / case
- TSSOP-14
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,730 in stock
#C54529
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹50.88 | ₹254.40 |
| 50+ | ₹39.84 | ₹1,992.00 |
| 150+ | ₹35.10 | ₹5,265.00 |
| 500+ | ₹29.20 | ₹14,600.00 |
| 2,000+ | ₹26.57 | ₹53,140.00 |
| 4,000+ | ₹24.99 | ₹99,960.00 |
5 × ₹50.88
₹254.40
excl. GST
₹300.19 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,000 per reel
SN74AHC125PWR
₹254.40 for 5 + GST
Specifications
- Function
- Output enable
- Current - Output High(IOH)
- 8mA
- Voltage - Supply
- 2V~5.5V
- Series
- 74AHC
- Output Type
- Tri-State
- Current - Output Low(IOL)
- 8mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 4
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 40uA
- Propagation Delay
- 5.3ns@5V,50pF
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.204 g
Overview
The 'AHC125 devices are quadruple bus buffer gates featuring independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable (OE) input is high. When OE is low, the respective gate passes the data from the A input to its Y output. To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
Applications
- Bus driving applications
Key features
- Latch-Up Performance Exceeds 250 mA Per JESD 17
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| SN74AHC125MPWREP#C2877094TI · TSSOP-14 | TI | TSSOP-14 | 8 | ₹393.39 · 8 in stock | View | |
 | 74AHC126PW,118#C554227Nexperia · TSSOP-14 | Nexperia | TSSOP-14 | 5 | ₹16.46 · 5 in stock | View |
 | 74AHC125PW,118#C503422Nexperia · TSSOP-14 | Nexperia | TSSOP-14 | 275 | ₹26.63 · 275 in stock | View |
 | 74AHC125T14-13#C526328DIODES · TSSOP-14 | DIODES | TSSOP-14 | 20 | ₹26.54 · 20 in stock | View |
| 74AHC125PW-Q100,11#C554220Nexperia · TSSOP-14 | Nexperia | TSSOP-14 | 57 | ₹71.07 · 57 in stock | View | |
