SN74AHC1G02DBVR
Schmitt trigger 2V~5.5V 7.5ns@5V,50pF 1uA SOT-23-5 Gates and Inverters RoHS
SOT-23-5ROHS3 CompliantActive
SINGLE 2-INPUT POSITIVE-NOR GATE
- Manufacturer
- TI
- Manufacturer part #
- SN74AHC1G02DBVR
- Store part #
- C7463
- Package / case
- SOT-23-5
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
14,710 in stock
#C7463
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹13.40 | ₹67.00 |
| 50+ | ₹10.31 | ₹515.50 |
| 150+ | ₹8.76 | ₹1,314.00 |
| 500+ | ₹7.61 | ₹3,805.00 |
| 3,000+ | ₹6.03 | ₹18,090.00 |
| 6,000+ | ₹5.57 | ₹33,420.00 |
5 × ₹13.40
₹67.00
excl. GST
₹79.06 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74AHC1G02DBVR
₹67.00 for 5 + GST
Specifications
- Input Type
- Schmitt trigger
- output type
- Push-pull
- Logic Family
- 74AHC Series
- Voltage - Supply
- 2V~5.5V
- Output Logic Level - Low
- 440mV
- Propagation Delay
- 7.5ns@5V,50pF
- Input Logic Level - Low
- 500mV~1.65V
- Input Logic Level - High
- 1.5V~3.85V
- Operating Temperature
- -40℃~+85℃
- Output Logic Level - High
- 3.8V
- Quiescent Current(Iq)
- 1uA
- Current - Output High(IOH)
- 8mA
- Number of Channels
- 1;2
- Current - Output Low(IOL)
- 8mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.041 g
Overview
This device contains a single 2-input NOR gate that performs the Boolean function Y = A(overline) • B(overline) or Y = (A + B)(overline) in positive logic.
Key features
- Operating Range of 2 V to 5.5 V
- Max tpd of 6.5 ns at 5 V
- Low Power Consumption, 10 μA Max Icc
- ±8 mA Output Drive at 5 V
- Schmitt Trigger Action at All Inputs Makes the Circuit tolerant for Slower Input Rise and Fall Time
- ESD Protection Exceeds JESD 22: 2000 V Human-Body Model (A114-A), 200 V Machine Model (A115-A), 1000 V Charged-Device Model (C101)
