SN74HC02N
2uA 2V~6V 15ns@6V,50pF DIP-14 Gates and Inverters RoHS
DIP-14ROHS3 CompliantActive
QUADRUPLE 2-INPUT POSITIVE-NOR GATES
- Manufacturer
- TI
- Manufacturer part #
- SN74HC02N
- Store part #
- C2897
- Package / case
- DIP-14
- Category
- Gates and Inverters
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,229 in stock
#C2897
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹110.36 | ₹110.36 |
| 10+ | ₹92.77 | ₹927.70 |
| 25+ | ₹83.86 | ₹2,096.50 |
| 100+ | ₹75.17 | ₹7,517.00 |
| 500+ | ₹69.75 | ₹34,875.00 |
| 1,000+ | ₹67.14 | ₹67,140.00 |
1 × ₹110.36
₹110.36
excl. GST
₹130.22 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 25 per tube
SN74HC02N
₹110.36 for 1 + GST
Specifications
- Input Logic Level - High
- 1.5V~4.2V
- Input Logic Level - Low
- 500mV~1.8V
- Operating Temperature
- -40℃~+85℃
- Logic Family
- 74HC Series
- Output Logic Level - High
- 1.9V;3.98V;5.48V
- Quiescent Current(Iq)
- 2uA
- Voltage - Supply
- 2V~6V
- Current - Output High(IOH)
- 5.2mA
- Number of Channels
- 4;2
- Output Logic Level - Low
- 100mV;400mV
- Propagation Delay
- 15ns@6V,50pF
- Current - Output Low(IOL)
- 5.2mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tube-packed
- Standard pack
- 25 / Tube
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 1.84 g
Overview
The ’HC02 devices contain four independent 2-input NOR gates. They perform the Boolean function Y = (A + B) (overline) or Y = A (overline) • B (overline) in positive logic.
Key features
- Wide Operating Voltage Range of δ₂V for all to 6 V
- Outputs Can Drive Up To 10 LSTTL Loads
- Low Power Consumption, 20 μA Max ICC
- Typical propagation delay time (tpd) = 8 ns ± 4 ns Output Drive at 5 V
- Low Input Current of 1 μA Max
