SN74LS126DR(LX)

1 Element 4 Bit per Element Tri-State Output SOP-14

SOP-14RoHSActive

4-channel buffer/line driver with three-state control

Manufacturer: lingxingic
Manufacturer part #: SN74LS126DR(LX)
Store part #: C22384765
Package / case: SOP-14
Category: Buffers, Drivers, Receivers, Transceivers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

1,195 in stock

#C22384765

Stock & price checked 3 days ago

Quantity	Unit price	Pack price
5+	₹34.25	₹171.25
50+	₹29.93	₹1,496.50
150+	₹28.06	₹4,209.00
500+	₹25.80	₹12,900.00
2,500+	₹24.77	₹61,925.00
5,000+	₹24.14	₹1,20,700.00

Quantity (min 5, multiples of 5)

5 × ₹34.25

₹171.25

excl. GST

₹202.08 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,500 per reel

SN74LS126DR(LX)

₹171.25 for 5 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Function: Output enable
Current - Output High(IOH): 7.8mA
Series: 74LS Series
Voltage - Supply: 2V~6V
Output Type: Tri-State
Current - Output Low(IOL): 7.8mA
Number of Bits per Element: 4
Channel Type: Unidirectional
Operating Temperature: -40℃~+125℃
Number of Elements: 1
Quiescent Supply Current: 160uA
Propagation Delay: 9ns@5V,15pF

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Moisture sensitivity: MSL 3 (168 hours)
Packaging: Tape & Reel (TR)
Standard pack: 2,500 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.257 g

Overview

SN74LS126 is a quad buffer/line driver with 3-state outputs controlled by output enable inputs (nOE). When nOE is low, the outputs are in a high-impedance state. The outputs have built-in clamp diodes, allowing input interfacing to voltages exceeding VCC using current-limiting resistors.
