SN74LVC1G125DBVR-TP
1.65V~5.5V 1 2.6ns@5V,50pF SOT-23-5 Buffers, Drivers, Receivers, Transceivers
SOT-23-5RoHSActive
BUS BUFFER/LINE DRIVER 3-STATE
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SN74LVC1G125DBVR-TP
- Store part #
- C3040625
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
15 in stock
#C3040625
Stock & price checked 28 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹11.29 | ₹56.45 |
| 50+ | ₹8.98 | ₹449.00 |
| 150+ | ₹7.83 | ₹1,174.50 |
| 500+ | ₹6.97 | ₹3,485.00 |
| 3,000+ | ₹6.10 | ₹18,300.00 |
| 6,000+ | ₹5.76 | ₹34,560.00 |
5 × ₹11.29
₹56.45
excl. GST
₹66.61 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G125DBVR-TP
₹56.45 for 5 + GST
Specifications
- Function
- Power-off isolation
- Current - Output High(IOH)
- 24mA
- Series
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Output Type
- Tri-State
- Current - Output Low(IOL)
- 24mA
- Channel Type
- Unidirectional
- Operating Temperature
- -40℃~+125℃
- Number of Elements
- 1
- Quiescent Supply Current
- 2uA
- Propagation Delay
- 2.6ns@5V,50pF
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.037 g
Overview
Key features
- Wide operating temperature range: Topr = -40 to 125 °C
- High output current: ±24 mA (min) at VCC = 3.0 V
- Super high speed operation: tpd = 2.6 ns (typ.) at VCC = 5.0 V, CL = 50 pF
- Operation voltage range: VCC = 1.65 to 5.5 V
- 5.5 V tolerant inputs
- 5.5 V power down protection output
