SN74LVC244ANSR

Buffer Driver Tri-State Output SO-20-300mil

SO-20-208milROHS3 CompliantActive

SN74LVC244A Octal Buffers or Drivers with Three-State Outputs

Manufacturer: TI
Manufacturer part #: SN74LVC244ANSR
Store part #: C2675722
Package / case: SO-20-208mil
Category: Buffers, Drivers, Receivers, Transceivers
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,581 in stock

#C2675722

Stock & price checked 46 h ago

Quantity	Unit price	Pack price
1+	₹111.87	₹111.87
10+	₹96.96	₹969.60
30+	₹86.39	₹2,591.70
100+	₹77.75	₹7,775.00
500+	₹74.95	₹37,475.00
1,000+	₹73.43	₹73,430.00

Quantity (min 1)

1 × ₹111.87

₹111.87

excl. GST

₹132.01 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 15-18 working days
GST invoice with every order
Standard pack: 2,000 per reel

SN74LVC244ANSR

₹111.87 for 1 + GST

Need this with the rest of your board? Upload the BOM — we price every line.Upload BOM

Specifications

Voltage - Supply: 1.65V~3.6V
Output Type: Tri-State
Operating Temperature: -40℃~+125℃
Quiescent Supply Current: 40uA
Function: Output enable;Level shifting
Current - Output High(IOH): 24mA
Series: 74LVC
Current - Output Low(IOL): 24mA
Number of Bits per Element: 4
Channel Type: Unidirectional
Number of Elements: 2
Propagation Delay: 3.9ns@3.3V,50pF

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
Moisture sensitivity: MSL 1 (unlimited)
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 2,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 1.44 g

Overview

These octal bus buffers are designed for 1.65V to 3.6V VCC operation. The SN74LVC244A device is designed for asynchronous communication between data buses.

Applications

Servers
LED displays
Network switch telecom infrastructure
Motor driver I/O expanders

Key features

Operating voltage range: 1.65V to 3.6V
Input voltage up to 5.5V
Rated operating temperature range: -40℃ to +85℃ and -40℃ to +125℃
tpd max 5.9ns at 3.3V
VOLP (output ground bounce) typical < 0.8V (VCC = 3.3V, TA = 25℃)
VOHV (output VOH undershoot) typical > 2V (VCC = 3.3V, TA = 25℃)
All ports support mixed-mode signal operation (5V input or output voltage with 3.3V VCC)
Ioff supports hot insertion, partial power-down mode, and back-drive protection
Functions as a down translator, stepping down input voltages up to 5.5V to VCC level
Ultra-small logic QFN package (max height 0.5mm)
Latch-up performance exceeds 250mA per JESD 17
ESD protection exceeds JESD 22 specifications
2000V Human Body Model
1000V Charged Device Model
