TL082CN(LX)
2 2mV 14V/us 30pA 86dB 1.2mA 1.3MHz DIP-8 Instrumentation, Op Amps, Buffer Amps
DIP-8RoHSActive
- Manufacturer
- lingxingic
- Manufacturer part #
- TL082CN(LX)
- Store part #
- C49396714
- Package / case
- DIP-8
- Packaging
- Tube-packed
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,125 in stock
#C49396714
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹22.35 | ₹111.75 |
| 50+ | ₹17.45 | ₹872.50 |
| 150+ | ₹15.36 | ₹2,304.00 |
| 500+ | ₹12.74 | ₹6,370.00 |
| 2,000+ | ₹11.56 | ₹23,120.00 |
| 4,000+ | ₹10.88 | ₹43,520.00 |
5 × ₹22.35
₹111.75
excl. GST
₹131.86 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 50 per tube
TL082CN(LX)
₹111.75 for 5 + GST
Specifications
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 2mV
- Slew Rate
- 14V/us
- Input Offset Current(Ios)
- 5pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 30pA
- Common Mode Rejection Ratio(CMRR)
- 86dB
- Input Offset Voltage Drift(Vos TC)
- 18uV/℃
- Quiescent Current
- 1.2mA
- Gain Bandwidth Product
- 1.3MHz
- Input Voltage Noise Density
- 8nV/√Hz@1kHz
- Dual Supply
- -15V~-5V;5V~15V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tube-packed
- Standard pack
- 50 / Tube
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 1 g
Overview
TL082 is a low-noise dual-channel op-amp with JFET inputs, primarily designed for audio amplification and other systems requiring low noise. It features substrate grounding and is available in DIP8 and SOP8 packages.
Key features
- Low input noise: 18 nV/√Hz (typical)
- Low distortion: 0.01% (typical)
- Low input current and low offset current
- High input impedance: 10^12 Ω (typical)
- High slew rate: 13 V/μs (typical)
- High bandwidth: 3.5 MHz (typical)
