TL082CPT

40mA 2 3mV 16V/us 86dB 20pA 1.4mA 4MHz TSSOP-8 Instrumentation, Op Amps, Buffer Amps RoHS

TSSOP-8ROHS3 CompliantActive

General purpose JFET dual operation amplifiers

Manufacturer: ST
Manufacturer part #: TL082CPT
Store part #: C2652280
Package / case: TSSOP-8
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

3,760 in stock

#C2652280

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹42.87	₹214.35
50+	₹33.49	₹1,674.50
150+	₹29.46	₹4,419.00
500+	₹24.45	₹12,225.00
2,500+	₹22.23	₹55,575.00
4,000+	₹20.88	₹83,520.00

Quantity (min 5, multiples of 5)

5 × ₹42.87

₹214.35

excl. GST

₹252.93 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 4,000 per reel

TL082CPT

₹214.35 for 5 + GST

Specifications

Output Current: 40mA
Number of Channels: 2
Vos - Input Offset Voltage: 3mV
Slew Rate: 16V/us
Input Offset Current(Ios): 5pA
Operating Temperature: 0℃~+70℃
Common Mode Rejection Ratio(CMRR): 86dB
Ib - Input Bias Current: 20pA
Input Offset Voltage Drift(Vos TC): 10uV/℃
Quiescent Current: 1.4mA
Gain Bandwidth Product: 4MHz
Features: Built-in compensation;Short-Circuit Protection;Latch-up suppression
Input Voltage Noise Density: 15nV/√Hz@1kHz
Dual Supply: -18V~-6V;6V~18V
Single Supply: 6V~36V

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 4,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.163 g

Overview

The TL082, TL082A and TL082B are high speed JFET input dual operational amplifiers incorporating well-matched, high voltage JFET and bipolar transistors in a monolithic integrated circuit. The devices feature high slew rates, low input bias and offset current, and low offset voltage temperature coefficient.
