HGSEMIDatasheet (PDF)
TL084CM/TR
Standard (General Purpose) Amplifier 4 Circuit SOP-14
SOP-14RoHSActive
High-Speed Quad J-FET Input Operational Amplifier
- Manufacturer
- HGSEMI
- Manufacturer part #
- TL084CM/TR
- Store part #
- C5310776
- Package / case
- SOP-14
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,270 in stock
#C5310776
Stock & price checked 37 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹36.50 | ₹182.50 |
| 50+ | ₹28.87 | ₹1,443.50 |
| 150+ | ₹25.59 | ₹3,838.50 |
| 500+ | ₹21.50 | ₹10,750.00 |
| 2,500+ | ₹18.77 | ₹46,925.00 |
| 5,000+ | ₹17.68 | ₹88,400.00 |
5 × ₹36.50
₹182.50
excl. GST
₹215.35 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
TL084CM/TR
₹182.50 for 5 + GST
Specifications
- Output Current
- 60mA
- Number of Channels
- 4
- Vos - Input Offset Voltage
- 13mV
- Slew Rate
- 16V/us
- Input Offset Current(Ios)
- 4nA
- Operating Temperature
- 0℃~+70℃
- Common Mode Rejection Ratio(CMRR)
- 75dB
- Ib - Input Bias Current
- 20nA
- Gain Bandwidth Product
- 4MHz
- Quiescent Current
- 1.4mA
- Features
- Built-in compensation
- Dual Supply
- -18V~18V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 3 (168 hours)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.29 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | TL084IM/TR#C7432341HGSEMI · SOP-14 | HGSEMI | SOP-14 | 940 | ₹38.00 · 940 in stock | View |
 | AD8054M/TR#C7432382HGSEMI · SOP-14 | HGSEMI | SOP-14 | 2,310 | ₹55.69 · 2,310 in stock | View |
| LM6144M/TR#C44606405HGSEMI · SOP-14 | HGSEMI | SOP-14 | On request | ₹249.99 · 0 in stock | View | |
