TECH PUBLIC

TP1001S3

25mA 1 -500mV~5V 4uA SOT-23-3 Instrumentation, Op Amps, Buffer Amps

SOT-23-3RoHSActive

High Side Current Monitor

Manufacturer: TECH PUBLIC
Manufacturer part #: TP1001S3
Store part #: C521983
Package / case: SOT-23-3
Category: Instrumentation, Op Amps, Buffer Amps
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,941 in stock

#C521983

Stock & price checked 5 days ago

Quantity	Unit price	Pack price
1+	₹85.39	₹85.39
10+	₹69.31	₹693.10
30+	₹61.27	₹1,838.10
100+	₹53.45	₹5,345.00
500+	₹44.98	₹22,490.00
1,000+	₹42.59	₹42,590.00

Quantity (min 1)

1 × ₹85.39

₹85.39

excl. GST

₹100.76 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

TP1001S3

₹85.39 for 1 + GST

Specifications

Output Current: 25mA
Number of Channels: 1
Vcm - Common Mode Voltage: -500mV~5V
Operating Temperature: -40℃~+85℃
-3dB Bandwidth: 300kHz
Quiescent Current: 4uA
Features: High-side detection;Analog output interface
Single Supply: 2.5V~20V

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 1
Unit weight: 0.11 g

Overview

The TP1001S3 is a high side current sense monitor. Using this device eliminates the need to disrupt the ground plane when sensing a load current. It takes a high side voltage developed across a current shunt resistor and translates it into a proportional output current. A user defined output resistor scales the output current into a ground-referenced voltage. The wide input voltage range of 20V down to as low as 2.5V make it suitable for a range of applications. A minimum operating current of just 4μA, combined with a SOT23 package make it a unique solution for portable battery equipment.
