MDD(Microdiode Semiconductor)Datasheet (PDF)
74AHCT1G126GV
2V~5.5V 1 1 5ns@5V SOT-23-5L Buffers, Drivers, Receivers, Transceivers
SOT-23-5LRoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74AHCT1G126GV
- Store part #
- C52140416
- Package / case
- SOT-23-5L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11,582 in stock
#C52140416
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹13.53 | ₹13.53 |
| 10+ | ₹10.68 | ₹106.80 |
| 30+ | ₹9.23 | ₹276.90 |
| 100+ | ₹8.16 | ₹816.00 |
| 500+ | ₹7.30 | ₹3,650.00 |
| 1,000+ | ₹6.87 | ₹6,870.00 |
1 × ₹13.53
₹13.53
excl. GST
₹15.97 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74AHCT1G126GV
₹13.53 for 1 + GST
Specifications
- Voltage - Supply
- 2V~5.5V
- Output Type
- Tri-State
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 40uA
- Function
- Output enable;Level shifting
- Current - Output High(IOH)
- 8mA
- Series
- 74AHCT
- Current - Output Low(IOL)
- 8mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Propagation Delay
- 5ns@5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.081 g
Overview
74AHC1G126 and 74AHCT1G126 are single buffer/line drivers with 3-state outputs. Their inputs are 5V tolerant, allowing these devices to be used as level translators in mixed-voltage environments.
Key features
- Wide supply voltage range: 2.0V ~ 5.5V
- Input overvoltage tolerance up to 5.5V
- High noise immunity
- CMOS low power consumption
- Latch-up performance exceeds 200 mA
- Symmetrical output impedance
- Balanced propagation delay
- Input levels: CMOS level for 74AHC1G126; TTL level for 74AHCT1G126
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3A exceeds 7000 V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
- Multiple package options
