NexperiaDatasheet (PDF)
74HC1G32GW,125
StandardCMOS 2V~6V 23ns@6V,50pF 20uA SOT-353 Gates and Inverters RoHS
SOT-353ROHS3 CompliantActive
2-input OR gate
- Manufacturer
- Nexperia
- Manufacturer part #
- 74HC1G32GW,125
- Store part #
- C10236
- Package / case
- SOT-353
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,020 in stock
#C10236
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.86 | ₹64.30 |
| 50+ | ₹10.25 | ₹512.50 |
| 150+ | ₹8.96 | ₹1,344.00 |
| 500+ | ₹7.98 | ₹3,990.00 |
| 3,000+ | ₹7.20 | ₹21,600.00 |
| 6,000+ | ₹6.80 | ₹40,800.00 |
5 × ₹12.86
₹64.30
excl. GST
₹75.87 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74HC1G32GW,125
₹64.30 for 5 + GST
Specifications
- Input Type
- StandardCMOS
- Logic Family
- 74HC Series
- Voltage - Supply
- 2V~6V
- Output Logic Level - Low
- 100mV;330mV;400mV
- Propagation Delay
- 23ns@6V,50pF
- Input Logic Level - High
- 1.5V~4.2V
- Input Logic Level - Low
- 500mV~1.8V
- Operating Temperature
- -40℃~+125℃
- Output Logic Level - High
- 1.9V;4.4V;5.9V
- Quiescent Current(Iq)
- 20uA
- Current - Output High(IOH)
- 2.6mA
- Number of Channels
- 1;2
- Current - Output Low(IOL)
- 2.6mA
Packaging & compliance
- RoHS
- ROHS3 Compliant
- Lifecycle
- Active
- ECCN
- EAR99
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.04 g
Overview
The 74HC1G32; 74HCT1G32 is a single 2-input OR gate. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC.
Applications
- Logic circuit design
- Digital circuit applications
- Low-power devices
- High noise immunity systems
- Wide voltage range applications
Key features
- Wide supply voltage range from 2.0 V to 6.0 V
- Symmetrical output impedance
- High noise immunity
- CMOS low power dissipation
- Balanced propagation delays
- Latch-up performance exceeds 100 mA per JESD78 Class II Level B
- Input levels: For 74HC1G32: CMOS level For 74HCT1G32: TTL level
- Complies with JEDEC standards: JESD8C (2.7 V to 3.6 V) JESD7A (2.0 V to 6.0 V)
- ESD protection HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
- Specified from -40℃ to +85℃ and from -40℃ to +125℃
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
| 74HC1G32GW-Q100#C4471492Nexperia · TSSOP-5 | Nexperia | TSSOP-5 | 440 | ₹29.93 · 440 in stock | View | |
| 74HC1G32GW-Q100H#C546704Nexperia · TSSOP-5-1.3mm | Nexperia | TSSOP-5-1.3mm | 2,965 | ₹19.05 · 2,965 in stock | View | |
 | MC74HC1G32DFT1G-TP#C52205175TECH PUBLIC · SOT-353 | TECH PUBLIC | SOT-353 | 2,860 | ₹5.77 · 2,860 in stock | View |
 | 74HC1G32GW#C52205105TECH PUBLIC · SOT-353 | TECH PUBLIC | SOT-353 | 1,170 | ₹6.24 · 1,170 in stock | View |
 | 74AHC1G32GW,125#C12489Nexperia · SOT-353 | Nexperia | SOT-353 | 14,105 | ₹11.60 · 14,105 in stock | View |
