74LVC1G02W5-TP
₹58.50 for 10 + GST
Specifications
- Features
- Local shutdown mode
- Operating Temperature
- -40℃~+125℃
- Logic Family
- 74LVC
- Output Logic Level - High
- 1.2V;1.9V;2.4V;3.8V
- Quiescent Current(Iq)
- 10uA
- Voltage - Supply
- 1.6V~5.5V
- Current - Output High(IOH)
- 24mA
- Number of Channels
- 1;2
- Output Logic Level - Low
- 450mV;300mV;400mV;550mV
- Propagation Delay
- 3.4ns@5V,15pF
- Current - Output Low(IOL)
- 24mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.036 g
Overview
74LVC1G02 is a 2-input NOR gate that implements the positive-logic function Y = A+B (with overline). The device incorporates a power-off protection circuit to prevent damage during power-down conditions.
Applications
- Voltage level translation
- General-purpose logic
- Power-down signal isolation
Key features
- Operating voltage range: 1.6V ~ 5.5V
- Low quiescent current: I_CC = 10μA (max)
- ±24mA output drive capability (VCC=3.0V)
- Power-loss protection
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74LVC1G02DBVR-TP#C41348120TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 4,070 | ₹6.76 · 4,070 in stock | View |
 | NC7SZ02M5X#C41348081TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 1,280 | ₹6.35 · 1,280 in stock | View |
 | 74LVC1G02GV#C41348122TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 2,670 | ₹5.40 · 2,670 in stock | View |
 | TP74LVC1G02S5#C42460125TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 4,320 | ₹7.44 · 4,320 in stock | View |
 | TC7SZ02F-TP#C54195029TECH PUBLIC · SOT-23-5 | TECH PUBLIC | SOT-23-5 | 3,000 | ₹5.81 · 3,000 in stock | View |
