SN74LVC1G02DBVR-TP
10uA 1.6V~5.5V 4.5ns@3.3V,50pF SOT-23-5 Gates and Inverters
SOT-23-5RoHSActive
SINGLE 2-INPUT NOR GATE
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SN74LVC1G02DBVR-TP
- Store part #
- C41348120
- Package / case
- SOT-23-5
- Category
- Gates and Inverters
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
4,070 in stock
#C41348120
Stock & price checked 32 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.76 | ₹67.60 |
| 100+ | ₹5.13 | ₹513.00 |
| 300+ | ₹4.31 | ₹1,293.00 |
| 3,000+ | ₹3.70 | ₹11,100.00 |
| 6,000+ | ₹3.23 | ₹19,380.00 |
| 9,000+ | ₹2.98 | ₹26,820.00 |
10 × ₹6.76
₹67.60
excl. GST
₹79.77 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G02DBVR-TP
₹67.60 for 10 + GST
Specifications
- Features
- Local shutdown mode
- Input Logic Level - Low
- 700mV;800mV
- Operating Temperature
- -40℃~+125℃
- Logic Family
- 74LVC
- Input Logic Level - High
- 1.7V;2V
- Output Logic Level - High
- 1.2V;1.9V;2.4V;3.8V
- Quiescent Current(Iq)
- 10uA
- Voltage - Supply
- 1.6V~5.5V
- Current - Output High(IOH)
- 24mA
- Number of Channels
- 1;2
- Propagation Delay
- 4.5ns@3.3V,50pF
- Output Logic Level - Low
- 450mV;300mV;550mV
- Current - Output Low(IOL)
- 24mA
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.036 g
Overview
SN74LVC1G02 is a single 2-input NOR gate implementing the function Y = Ā+B̄ in positive logic. The device features power-off protection circuitry to prevent damage during power-down conditions.
Applications
- Audio docking stations
- Blu-ray players and home theater systems
- Personal digital assistants
- Solid-state drives
- Wireless headsets, keyboards, and mice
Key features
- Operating voltage range: 1.65V ~ 5.5V
- Output drive capability: ±24mA (at VCC=3.0V)
- High noise immunity
- Power-off protection
- ESD protection exceeds JESD 22: HBM 2000V (A114-A), MM 200V (A115-A), CDM 1000V (C101)
