MDD(Microdiode Semiconductor)Datasheet (PDF)
74LVC1G07GV
Schmitt trigger 1.65V~5.5V 1 1 2.6ns@5V SOT-23-5L Buffers, Drivers, Receivers, Transceivers
SOT-23-5LRoHSActive
- Manufacturer
- MDD(Microdiode Semiconductor)
- Manufacturer part #
- 74LVC1G07GV
- Store part #
- C52140414
- Package / case
- SOT-23-5L
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,793 in stock
#C52140414
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹11.83 | ₹11.83 |
| 10+ | ₹9.33 | ₹93.30 |
| 30+ | ₹8.07 | ₹242.10 |
| 100+ | ₹7.13 | ₹713.00 |
| 500+ | ₹6.39 | ₹3,195.00 |
| 1,000+ | ₹6.01 | ₹6,010.00 |
1 × ₹11.83
₹11.83
excl. GST
₹13.96 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC1G07GV
₹11.83 for 1 + GST
Specifications
- Input type
- Schmitt trigger
- Voltage - Supply
- 1.65V~5.5V
- Output Type
- Open-drain
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 4uA
- Function
- Power-off isolation;Level shifting
- Series
- 74LVC
- Current - Output Low(IOL)
- 32mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Propagation Delay
- 2.6ns@5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.082 g
Overview
The 74LVC1G07 is a single buffer with open-drain output. The input can be driven by 3.3V or 5V devices. This feature allows the device to be used as a level translator in mixed 3.3V and 5V environments. Schmitt-trigger action on all inputs makes the circuit tolerant of slower input rise and fall times. The device is fully specified for partial power-down applications using IOFF. The IOFF circuit disables the outputs, preventing potentially damaging backflow current through the device when it is powered down.
Key features
- Wide supply voltage range: 1.65 V ~ 5.5 V
- Overvoltage-tolerant inputs up to 5.5 V
- High noise immunity
- CMOS low power consumption
- I<sub>OFF</sub> circuitry enables partial power-down mode operation
- ±24 mA output drive capability (V<sub>CC</sub> = 3.0 V)
- Latch-up performance exceeds 100 mA
- Direct interface with TTL levels
- JEDEC standards compliant: JESD8-7 (1.65 V to 1.95 V), JESD8-5 (2.3 V to 2.7 V), JESD8C (2.7 V to 3.6 V), JESD36 (4.5 V to 5.5 V)
- ESD protection: HBM ANSI/ESDA/JEDEC JS-001 Class 3B exceeds 8000 V; MM JESD22-A115C Class C exceeds 550 V; CDM ANSI/ESDA/JEDEC JS-002 Class C3 exceeds 2000 V
- Multiple package options
