ES490EESA
1/1 Transceiver Full RS422, RS485 SOP-8
SOP-8ROHS CompliantActive
ES490E RS-485/RS422 Transceiver
- Manufacturer
- ElecSuper
- Manufacturer part #
- ES490EESA
- Store part #
- C41438282
- Package / case
- SOP-8
- Category
- Drivers, Receivers, Transceivers
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,306 in stock
#C41438282
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹45.63 | ₹45.63 |
| 10+ | ₹39.77 | ₹397.70 |
| 30+ | ₹37.16 | ₹1,114.80 |
| 100+ | ₹33.90 | ₹3,390.00 |
| 500+ | ₹32.60 | ₹16,300.00 |
| 1,000+ | ₹31.73 | ₹31,730.00 |
1 × ₹45.63
₹45.63
excl. GST
₹53.84 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 2,500 per reel
ES490EESA
₹45.63 for 1 + GST
Specifications
- Voltage - Supply
- 4.5V~5.5V
- Type
- Transceiver
- Data Rate
- 14Mbps
- Operating Temperature
- -40℃~+125℃
- Number of Nodes
- 256
- ESD Protect
- ±15kV
- Communication Mode
- Full-Duplex
- Number of Drivers
- 1
- Features
- Overcurrent Protection
- Number of Receivers
- 1
- Quiescent Supply Current
- 240uA
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 2,500 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 0.198 g
Overview
4.5V~5.5V powered, full-duplex, low-power RS-485/RS-422 transceiver fully compliant with TIA/EIA-485 standard. Includes one driver and one receiver, both capable of independent signal transmission. Features 1/8 unit load, allowing up to 256 transceivers to be connected on the same bus. Supports error-free data transmission up to 14Mbps. Operating voltage range of 4.5V~5.5V with failsafe, current-limiting protection, and overvoltage protection. Excellent ESD immunity with HBM rating of ±15kV.
Key features
- 4.5V~5.5V supply voltage, full-duplex
- 1/8 unit load, supports up to 256 devices on the bus
- Driver short-circuit output protection
- Enhanced noise immunity
- Integrated transient voltage suppression
- Data transfer rate up to 14Mbps in electrically noisy environments
- A, B, Y, Z port protection: HBM ±15kV
