FBC4066YESOP8G/TR
Linear Charging IC Lithium-ion/Polymer ESOP-8
1000mA single-cell lithium battery charger IC
- Manufacturer
- Full-Way
- Manufacturer part #
- FBC4066YESOP8G/TR
- Store part #
- C41370612
- Package / case
- ESOP-8
- Category
- Battery Management
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
46,085 in stock
#C41370612
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.45 | ₹52.25 |
| 50+ | ₹9.27 | ₹463.50 |
| 150+ | ₹8.69 | ₹1,303.50 |
| 500+ | ₹8.24 | ₹4,120.00 |
| 2,500+ | ₹7.89 | ₹19,725.00 |
| 4,000+ | ₹7.71 | ₹30,840.00 |
5 × ₹10.45
₹52.25
excl. GST
₹61.65 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
FBC4066YESOP8G/TR
₹52.25 for 5 + GST
Specifications
- Operating Temperature
- -40℃~+85℃
- Quiescent Current
- 1.2uA
- Type of Battery
- Lithium Battery
- Operating Voltage
- 4.5V~6.5V
- Features
- Constant current charging;Constant voltage charging;Trickle charging;Automatic recharge;Charge termination;Programmable charging current;Overvoltage protection;Soft-start;Under-voltage lockout
- The Chip Type
- Charging IC
- Charge Current - Max
- 1A
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.184 g
Overview
A single-cell lithium-ion battery CC/CV linear charger with 30V input voltage tolerance and input overvoltage protection. The minimal external circuitry makes it ideal for portable device applications, compatible with both USB power and adapter power sources. The integrated internal PMOSFET architecture and anti-backflow circuit eliminate the need for external isolation diodes. A thermal feedback mechanism automatically adjusts the charging current to limit chip temperature during high-power operation or in high-temperature environments. The charge termination voltage is 4.2V, and the charging current is programmable via an external resistor. Charging terminates automatically when the current drops to one-fifth of the programmed value. When the input power source is removed, the device automatically enters a low-current sleep state, reducing standby current to zero.
Applications
- Charging dock
- Bluetooth headset
- GPS
- Mobile phone
- PDA
- MP3/MP4
- Digital camera
- Mini speakers and other portable devices
Key features
- Maximum input voltage: 30V
- Full charge voltage: 4.2V
- Overvoltage protection voltage: 7.3V
- Maximum charge current: 1000mA
- Trickle/constant current/constant voltage three-stage charging
- No external MOSFET, sense resistor, or blocking diode required
- Intelligent thermal regulation for maximum charge rate optimization
- Intelligent recharge function
- BAT input reverse polarity protection
- Standby mode quiescent current: 1.2μA
- C/5 charge termination
- Charge status indication
- Package: ESOP8
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | FBC4056YESOP8G/TR#C42421350Full-Way · ESOP-8 | Full-Way | ESOP-8 | 1,680 | ₹6.76 · 1,680 in stock | View |
