LM358D
Standard (General Purpose) Amplifier 2 Circuit SOP-8
SOP-8ROHS CompliantActive
1MHz high-voltage bipolar dual operational amplifier
- Manufacturer
- IDCHIP
- Manufacturer part #
- LM358D
- Store part #
- C2683482
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,06,000 in stock
#C2683482
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 20+ | ₹6.10 | ₹122.00 |
| 200+ | ₹5.04 | ₹1,008.00 |
| 600+ | ₹4.51 | ₹2,706.00 |
| 4,000+ | ₹3.19 | ₹12,760.00 |
| 8,000+ | ₹2.86 | ₹22,880.00 |
| 20,000+ | ₹2.71 | ₹54,200.00 |
20 × ₹6.10
₹122.00
excl. GST
₹143.96 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
LM358D
₹122.00 for 20 + GST
Specifications
- Output Current
- 120mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 7mV
- Slew Rate
- 300V/ms
- Input Offset Current(Ios)
- 5nA
- Operating Temperature
- -40℃~+85℃
- Ib - Input Bias Current
- 500nA
- Common Mode Rejection Ratio(CMRR)
- 80dB
- Input Offset Voltage Drift(Vos TC)
- 7uV/℃
- Quiescent Current
- 1.18mA
- Gain Bandwidth Product
- 1MHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 40nV/√Hz@1kHz
- Dual Supply
- -15V~-1.5V;1.5V~15V
- Single Supply
- 3V~30V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 20 (multiples of 20)
- Unit weight
- 0.15 g
Overview
The LM358D integrates two independent, high-gain, internally frequency-compensated dual op-amps, featuring a 1MHz gain-bandwidth product, a slew rate of 0.2V/μs, and a quiescent current of only 1.18mA at 5V supply. The LM358 is designed to deliver high-voltage, low-noise performance. This IC operates in both single-supply and dual-supply applications, and can comfortably drive large capacitive loads. Available in an SOP-8 package, the LM358 is a wide supply range, high-performance op-amp that meets diverse circuit application requirements without sacrificing board space.
Applications
- Chargers
- Power adapters
- Sensor amplifiers
- Piezoelectric sensor amplifiers
- Medical instruments
- Mobile communication devices
- Audio amplifier outputs
- Portable systems
- DC gain stages
- Differential amplifiers
- Inverting amplifiers
- Low-pass filters
- Voltage comparators
Key features
- Internal frequency compensation, high DC voltage gain (85dB)
- Unity gain bandwidth (1MHz)
- Low supply current (1.18mA)
- Low input bias current (45nA)
- Wide supply voltage range (+3V ~ 30V)
- Low input offset voltage and offset current
- Wide common-mode input voltage range
- Wide differential input voltage range
- Stable with high capacitive loads
