LMV358SR
45mA 2 1mV 1V/us 2.5pA 125dB 85uA 1.5MHz Rail-to-rail output SOP-8 Instrumentation, Op Amps, Buffer Amps RoHS
SOP-8ROHS CompliantActive
1.5MHz, Low Cost Micro Power Operational Amplifiers
- Manufacturer
- COSINE
- Manufacturer part #
- LMV358SR
- Store part #
- C5183763
- Package / case
- SOP-8
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
1,080 in stock
#C5183763
Stock & price checked 5 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹12.57 | ₹62.85 |
| 50+ | ₹10.04 | ₹502.00 |
| 150+ | ₹8.78 | ₹1,317.00 |
| 500+ | ₹7.83 | ₹3,915.00 |
| 2,500+ | ₹6.76 | ₹16,900.00 |
| 4,000+ | ₹6.38 | ₹25,520.00 |
5 × ₹12.57
₹62.85
excl. GST
₹74.16 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
LMV358SR
₹62.85 for 5 + GST
Specifications
- Output Current
- 45mA
- Number of Channels
- 2
- Vos - Input Offset Voltage
- 1mV
- Slew Rate
- 1V/us
- Input Offset Current(Ios)
- 2.5pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 2.5pA
- Common Mode Rejection Ratio(CMRR)
- 125dB
- Input Offset Voltage Drift(Vos TC)
- 5uV/℃
- Quiescent Current
- 85uA
- Gain Bandwidth Product
- 1.5MHz
- Features
- Built-in compensation
- Input Voltage Noise Density
- 28nV/√Hz@1kHz
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 2.1V~5.5V
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.18 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | COS358SR#C693055COSINE · SOIC-8 | COSINE | SOIC-8 | 12,990 | ₹11.76 · 12,990 in stock | View |
 | COS2314SR#C693066COSINE · SOIC-8 | COSINE | SOIC-8 | 260 | ₹24.95 · 260 in stock | View |
 | COS822SR#C693067COSINE · SOIC-8 | COSINE | SOIC-8 | 1,010 | ₹19.90 · 1,010 in stock | View |
 | COS6022SR#C18198084COSINE · SOP-8 | COSINE | SOP-8 | 175 | ₹20.20 · 175 in stock | View |
 | COS2374SR#C693068COSINE · SOIC-8 | COSINE | SOIC-8 | 7,990 | ₹25.97 · 7,990 in stock | View |
