MCP601T-I/OT-TUDI
70mA 1 800uV 9V/us 1pA 63dB 1.85mA 11MHz Rail-to-rail output SOT-23-5 Instrumentation, Op Amps, Buffer Amps
SOT-23-5RoHSActive
Single Supply CMOS Op Amps
- Manufacturer
- Tudi
- Manufacturer part #
- MCP601T-I/OT-TUDI
- Store part #
- C36533669
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,935 in stock
#C36533669
Stock & price checked 18 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹24.81 | ₹124.05 |
| 50+ | ₹21.66 | ₹1,083.00 |
| 150+ | ₹20.31 | ₹3,046.50 |
| 500+ | ₹18.63 | ₹9,315.00 |
| 2,500+ | ₹17.89 | ₹44,725.00 |
| 5,000+ | ₹17.44 | ₹87,200.00 |
5 × ₹24.81
₹124.05
excl. GST
₹146.38 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MCP601T-I/OT-TUDI
₹124.05 for 5 + GST
Specifications
- Output Current
- 70mA
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 800uV
- Slew Rate
- 9V/us
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 1pA
- Common Mode Rejection Ratio(CMRR)
- 63dB
- Input Offset Voltage Drift(Vos TC)
- 2.4uV/℃
- Quiescent Current
- 1.85mA
- Gain Bandwidth Product
- 11MHz
- Features
- Enable/shutdown function;Built-in compensation
- Input Voltage Noise Density
- 11.5nV/√Hz@1kHz
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 2.7V~5.5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2 (1 year)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.04 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MCP601RT-I/OT-TUDI#C41355586Tudi · SOT-23-5 | Tudi | SOT-23-5 | 22,795 | ₹32.33 · 22,795 in stock | View |
 | MCP606T-I/OT-TUDI#C36533689Tudi · SOT-23-5 | Tudi | SOT-23-5 | 2,312 | ₹49.65 · 2,312 in stock | View |
 | TSV911AIDBVR-TUDI#C54858217Tudi · SOT-23-5 | Tudi | SOT-23-5 | 195 | ₹32.78 · 195 in stock | View |
 | TSV911ILT-TUDI#C54858224Tudi · SOT-23-5 | Tudi | SOT-23-5 | 190 | ₹35.91 · 190 in stock | View |
