MCP606T-I/OT-TUDI
70mA 1 800uV 9V/us 1pA 82dB 11MHz 1.1mA Rail-to-rail output SOT-23-5 Instrumentation, Op Amps, Buffer Amps
SOT-23-5RoHSActive
Micropower CMOS Op Amp
- Manufacturer
- Tudi
- Manufacturer part #
- MCP606T-I/OT-TUDI
- Store part #
- C36533689
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,312 in stock
#C36533689
Stock & price checked 21 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 1+ | ₹49.65 | ₹49.65 |
| 10+ | ₹43.37 | ₹433.70 |
| 30+ | ₹40.76 | ₹1,222.80 |
| 100+ | ₹37.30 | ₹3,730.00 |
| 500+ | ₹35.79 | ₹17,895.00 |
| 1,000+ | ₹34.91 | ₹34,910.00 |
1 × ₹49.65
₹49.65
excl. GST
₹58.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
MCP606T-I/OT-TUDI
₹49.65 for 1 + GST
Specifications
- Output Current
- 70mA
- Number of Channels
- 1
- Vos - Input Offset Voltage
- 800uV
- Slew Rate
- 9V/us
- Input Offset Current(Ios)
- 1pA
- Operating Temperature
- -40℃~+125℃
- Ib - Input Bias Current
- 1pA
- Common Mode Rejection Ratio(CMRR)
- 82dB
- Input Offset Voltage Drift(Vos TC)
- 2.4uV/℃
- Gain Bandwidth Product
- 11MHz
- Quiescent Current
- 1.1mA
- Features
- Enable/shutdown function;Built-in compensation
- Input Voltage Noise Density
- 11.5nV/√Hz@1kHz
- Dual Supply
- -2.75V~-1.05V;1.05V~2.75V
- Rail to Rail
- Rail-to-rail output
- Single Supply
- 2.5V~5.5V
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Moisture sensitivity
- MSL 2 (1 year)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 1
- Unit weight
- 23.684 g
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | MCP601RT-I/OT-TUDI#C41355586Tudi · SOT-23-5 | Tudi | SOT-23-5 | 22,795 | ₹32.33 · 22,795 in stock | View |
 | MCP601T-I/OT-TUDI#C36533669Tudi · SOT-23-5 | Tudi | SOT-23-5 | 2,935 | ₹24.81 · 2,935 in stock | View |
 | TSV911AIDBVR-TUDI#C54858217Tudi · SOT-23-5 | Tudi | SOT-23-5 | 195 | ₹32.78 · 195 in stock | View |
 | TSV911ILT-TUDI#C54858224Tudi · SOT-23-5 | Tudi | SOT-23-5 | 190 | ₹35.91 · 190 in stock | View |
