SN74AUP1G17DRLR-TP
0.8V~3.6V 1 1 2.7ns@3.3V,5pF SOT-553 Buffers, Drivers, Receivers, Transceivers RoHS
SOT-553ROHS CompliantActive
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SN74AUP1G17DRLR-TP
- Store part #
- C49374609
- Package / case
- SOT-553
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
3,890 in stock
#C49374609
Stock & price checked 2 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 5+ | ₹10.93 | ₹54.65 |
| 50+ | ₹8.64 | ₹432.00 |
| 150+ | ₹7.50 | ₹1,125.00 |
| 500+ | ₹6.64 | ₹3,320.00 |
| 2,500+ | ₹5.95 | ₹14,875.00 |
| 4,000+ | ₹5.61 | ₹22,440.00 |
5 × ₹10.93
₹54.65
excl. GST
₹64.49 incl. 18% GST
- Dispatch in 15-18 working days
- GST invoice with every order
- Standard pack: 4,000 per reel
SN74AUP1G17DRLR-TP
₹54.65 for 5 + GST
Specifications
- Function
- Power-off isolation
- Series
- 74AUP
- Voltage - Supply
- 0.8V~3.6V
- Current - Output Low(IOL)
- 4mA
- Output Type
- Open-drain
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Operating Temperature
- -40℃~+125℃
- Number of Elements
- 1
- Quiescent Supply Current
- 500nA
- Propagation Delay
- 2.7ns@3.3V,5pF
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Moisture sensitivity
- MSL 1 (unlimited)
- Packaging
- Tape & Reel (TR)
- Standard pack
- 4,000 / Reel
- Sold per
- Piece
- Minimum order
- 5 (multiples of 5)
- Unit weight
- 0.031 g
Overview
This device provides a single non-inverting buffer with open-drain output. The open-drain output structure allows connection with other open-drain outputs to implement active-low wire-OR or active-high wire-AND functions.
Applications
- AV receivers
- Audio docking stations
- Blu-ray players & home theater systems
- Embedded PCs
- Personal digital assistants
Key features
- Wide supply voltage range: 0.8V to 3.6V
- Inputs tolerant up to 3.6V
- I<sub>OFF</sub> supports partial power-down mode
- Low quiescent current; I<sub>CC</sub> = 0.5μA (Max.)
- ESD protection exceeds JESD 22: HBM (A114-A) 2000V, MM (A115-A) 200V, CDM (C101) 1000V
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74AUP1G07DRLR-TP#C49333173TECH PUBLIC · SOT-553 | TECH PUBLIC | SOT-553 | 3,890 | ₹9.78 · 3,890 in stock | View |
 | TP74AUP1G07X5#C49333195TECH PUBLIC · SOT-553 | TECH PUBLIC | SOT-553 | 475 | ₹16.14 · 475 in stock | View |
 | SN74AUP1G125DRLR-TP#C49230998TECH PUBLIC · SOT553 | TECH PUBLIC | SOT553 | 245 | ₹16.33 · 245 in stock | View |
 | TP74AUP1G125X5#C49231006TECH PUBLIC · SOT553 | TECH PUBLIC | SOT553 | 250 | ₹19.30 · 250 in stock | View |
