SN74LVC1G126DBVR(UMW)
Buffer Non-Inverting SOT-23-5
SOT-23-5ROHS CompliantActive
Single-channel non-inverting buffer
- Manufacturer
- UMW
- Manufacturer part #
- SN74LVC1G126DBVR(UMW)
- Store part #
- C7394019
- Package / case
- SOT-23-5
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
11,860 in stock
#C7394019
Stock & price checked 7 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.55 | ₹65.50 |
| 100+ | ₹5.03 | ₹503.00 |
| 300+ | ₹4.27 | ₹1,281.00 |
| 3,000+ | ₹3.70 | ₹11,100.00 |
| 6,000+ | ₹3.25 | ₹19,500.00 |
| 9,000+ | ₹3.03 | ₹27,270.00 |
10 × ₹6.55
₹65.50
excl. GST
₹77.29 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC1G126DBVR(UMW)
₹65.50 for 10 + GST
Specifications
- Function
- Output enable
- Current - Output High(IOH)
- 24mA
- Series
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Current - Output Low(IOL)
- 24mA
- Output Type
- Tri-State
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Operating Temperature
- -40℃~+85℃
- Number of Elements
- 1
- Quiescent Supply Current
- 10uA
- Propagation Delay
- 5.6ns@3.3V,50pF
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.041 g
Overview
UMW SN74LVC1G126 is a high-performance single non-inverting buffer operating over a supply voltage range of 1.65V ~ 5.5V. The device is fabricated using advanced CMOS technology to achieve ultra-high speed and high output drive capability.
Key features
- Designed for 1.65V ~ 5.5V VCC operating voltage
- Overvoltage-tolerant inputs
- 24 mA balanced output sink and source current capability
- Near-zero quiescent supply current, significantly reducing system power consumption requirements
- Lead-free, RoHS compliant
- Active-low tri-state output enable input
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | SN74LVC1G125DBVR(UMW)#C7394017UMW · SOT-23-5 | UMW | SOT-23-5 | 1,20,510 | ₹6.81 · 1,20,510 in stock | View |
 | SN74LVC1G34DBVR(UMW)#C7394018UMW · SOT-23-5 | UMW | SOT-23-5 | 990 | ₹5.28 · 990 in stock | View |
 | SN74LVC1G07DBVR(UMW)#C7394020UMW · SOT-23-5 | UMW | SOT-23-5 | 9,300 | ₹5.94 · 9,300 in stock | View |
 | SN74LVC1G17DBVR(UMW)#C7394021UMW · SOT-23-5 | UMW | SOT-23-5 | 10,820 | ₹5.08 · 10,820 in stock | View |
