TECH PUBLIC

SN74LVC1G386DBVR-TP

1.65V~5.5V 5ns@5V,15pF 10uA SOT-23-6 Gates and Inverters

SOT-23-6RoHSActive

Manufacturer: TECH PUBLIC
Manufacturer part #: SN74LVC1G386DBVR-TP
Store part #: C51939613
Package / case: SOT-23-6
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,975 in stock

#C51939613

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹10.72	₹53.60
50+	₹8.43	₹421.50
150+	₹7.29	₹1,093.50
500+	₹6.43	₹3,215.00
3,000+	₹5.74	₹17,220.00
6,000+	₹5.40	₹32,400.00

Quantity (min 5, multiples of 5)

5 × ₹10.72

₹53.60

excl. GST

₹63.25 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

SN74LVC1G386DBVR-TP

₹53.60 for 5 + GST

Specifications

Logic Family: 74LVC
Voltage - Supply: 1.65V~5.5V
Output Logic Level - Low: 100mV;450mV;300mV;400mV;550mV
Propagation Delay: 5ns@5V,15pF
Input Logic Level - Low: 700mV;800mV
Input Logic Level - High: 1.7V;2V
Features: Local shutdown mode;Rear drive protection
Operating Temperature: -40℃~+125℃
Output Logic Level - High: 1.2V;1.9V;2.4V;2.3V;3.8V
Quiescent Current(Iq): 10uA
Current - Output High(IOH): 32mA
Number of Channels: 3;1
Current - Output Low(IOL): 32mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.035 g

Overview

The SN74LVC1G386DBVR-TP device performs the Boolean function Y = A ⊕ B ⊕ C in positive logic. The device is fully specified for partial-power-down applications using Ioff. The Ioff circuit disables the outputs, preventing damaging current backflow when the device is powered down.

Applications

AV Receiver
Audio Dock
Blu-ray Player & Home Theater
Embedded PC
Personal Digital Assistant
Power Supply

Key features

Wide supply voltage range: 1.65V to 5.5V
5V VCC operation support
IOFF for back-drive protection in partial power-down mode
Low power consumption, maximum ICC of 10μA
ESD protection exceeding JESD 22: HBM 2000V, MM 200V, CDM 1000V

Alternatives

Similar parts — check the datasheet before substituting.

Part		Manufacturer	Package	Stock	Price from (excl. GST)	Action
	74LVC1G386GV-TP#C51939530TECH PUBLIC · SOT-23-6	TECH PUBLIC	SOT-23-6	2,830	₹10.69 · 2,830 in stock	View
	TP74LVC1G386S6#C51939628TECH PUBLIC · SOT-23-6	TECH PUBLIC	SOT-23-6	2,200	₹12.85 · 2,200 in stock	View
