SN74LVC1G86DCKR

10uA 1.65V~5.5V 4ns@3.3V,15pF SOT-353 Gates and Inverters

SOT-353RoHSActive

SINGLE 2-INPUT EXCLUSIVE-OR GATE

Manufacturer: TECH PUBLIC
Manufacturer part #: SN74LVC1G86DCKR
Store part #: C19829633
Package / case: SOT-353
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

2,290 in stock

#C19829633

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
10+	₹6.71	₹67.10
100+	₹5.25	₹525.00
300+	₹4.52	₹1,356.00
3,000+	₹3.98	₹11,940.00
6,000+	₹3.55	₹21,300.00
9,000+	₹3.33	₹29,970.00

Quantity (min 10, multiples of 10)

10 × ₹6.71

₹67.10

excl. GST

₹79.18 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

SN74LVC1G86DCKR

₹67.10 for 10 + GST

Specifications

Features: Local shutdown mode
Input Logic Level - Low: 700mV;800mV
Operating Temperature: -40℃~+125℃
Logic Family: 74LVC
Input Logic Level - High: 1.7V;2V
Output Logic Level - High: 1.2V;1.9V;2.4V;2.3V;3.8V
Quiescent Current(Iq): 10uA
Voltage - Supply: 1.65V~5.5V
Number of Channels: 1;2
Current - Output High(IOH): 32mA
Propagation Delay: 4ns@3.3V,15pF
Output Logic Level - Low: 450mV;300mV;400mV;550mV
Current - Output Low(IOL): 32mA

Packaging & compliance

RoHS: RoHS
Lifecycle: Active
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 10 (multiples of 10)
Unit weight: 0.028 g

Overview

The SN74LVC1G86 is a single 2-input EXCLUSIVE-OR gate which provides the Function Y = A⊕B or Y = AB(overline) + AB(overline) in positive logic. Inputs can be driven from either 3.3V or 5V devices. These features allow the use of these devices in a mixed 3.3V and 5V environment. This device is fully specified for partial Power-down applications using lorF. The lorF circuitry disables the output, preventing the damaging backflow current through the device when it is powered down.

Applications

Voltage Level Shifting
General Purpose Logic
Power Down Signal Isolation
PCs, Networking, Notebooks, Netbooks, PDAs
Tablet Computers, E-readers
Computer Peripherals, Hard Drives, CD/DVD ROM
TV, DVD, DVR, Set-Top Box
Cell Phones, Personal Navigation/GPS
MP3 Players, Cameras, Video Recorders

Key features

Operate from 1.65V to 5.5V
Inputs accept voltages to 5.5V
loFF supports partial-power-down mode
Low power dissipation
Max tpD of 4 ns at 3.3V
SOT23-5 Package Available
SOT353 Package Available
SOT553 Package Available

Alternatives

Similar parts — check the datasheet before substituting.
