TECH PUBLICDatasheet (PDF)
SN74LVC2G04DBVR
1.65V~5.5V 1 2 3.2ns@5V,50pF SOT-23-6 Buffers, Drivers, Receivers, Transceivers
SOT-23-6RoHSActive
Dual Inverter
- Manufacturer
- TECH PUBLIC
- Manufacturer part #
- SN74LVC2G04DBVR
- Store part #
- C19829671
- Package / case
- SOT-23-6
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
6,530 in stock
#C19829671
Stock & price checked 6 days ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.83 | ₹68.30 |
| 100+ | ₹5.32 | ₹532.00 |
| 300+ | ₹4.56 | ₹1,368.00 |
| 3,000+ | ₹4.00 | ₹12,000.00 |
| 6,000+ | ₹3.55 | ₹21,300.00 |
| 9,000+ | ₹3.32 | ₹29,880.00 |
10 × ₹6.83
₹68.30
excl. GST
₹80.59 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
SN74LVC2G04DBVR
₹68.30 for 10 + GST
Specifications
- Function
- Power-off isolation
- Current - Output High(IOH)
- 32mA
- Series
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Current - Output Low(IOL)
- 32mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 2
- Quiescent Supply Current
- 10uA
- Propagation Delay
- 3.2ns@5V,50pF
Packaging & compliance
- RoHS
- RoHS
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.035 g
Overview
The SN74LVC2G04 is a dual inverter gate and it provides the Boolean function Y = A(overline) in positive logic. This device has power-down protective circuit to prevent the device from destruction when it is powered down.
Applications
- Voltage Level Shifting
- General Purpose Logic
- Power Down Signal Isolation
- PCs, Networking, Notebooks, Netbooks, PDAs Tablet Computers, E-readers
- Computer Peripherals, Hard Drives, CD/DVD ROM
- TV, DVD, DVR, Set-Top Box
- Cell Phones, Personal Navigation / GPS
- MP3 Players, Cameras, Video Recorders
Key features
- Operation voltage range: 1.65~5.5V
- Inputs Accept Voltages To 5.5V
- High noise immunity
- Low Power Dissipation
- Max tpD Of 3.2 ns At 5V
- SOT23-6 Package Available
- SOT363 Package Available
Alternatives
Similar parts — check the datasheet before substituting.
| Part | Manufacturer | Package | Stock | Price from (excl. GST) | Action | |
|---|---|---|---|---|---|---|
 | 74LVC2G34GV-TP#C49374611TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,670 | ₹6.02 · 2,670 in stock | View |
 | 74LVC2G14GV#C19829598TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 1,750 | ₹9.29 · 1,750 in stock | View |
 | SN74LVC2G14DBVR#C19829673TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 3,210 | ₹10.02 · 3,210 in stock | View |
 | SN74LVC2G34DBVR-TP#C49374610TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 1,910 | ₹6.02 · 1,910 in stock | View |
 | TP74LVC2G34S6#C49374612TECH PUBLIC · SOT-23-6 | TECH PUBLIC | SOT-23-6 | 2,660 | ₹7.10 · 2,660 in stock | View |
