74HCT1G08GW-Q100,1

TTL-compatible CMOS 4.5V~5.5V 11ns@4.5V,50pF 20uA TSSOP-5-1.3mm Gates and Inverters RoHS

TSSOP-5-1.3mmROHS3 CompliantActive

2-input AND gate

Manufacturer: Nexperia
Manufacturer part #: 74HCT1G08GW-Q100,1
Store part #: C547446
Package / case: TSSOP-5-1.3mm
Category: Gates and Inverters
Packaging: Tape & Reel (TR)

Datasheet (PDF)

Every Order Guarantee

100% Authentic · 30-Day Return or Replacement · policy

6,355 in stock

#C547446

Stock & price checked 6 days ago

Quantity	Unit price	Pack price
5+	₹22.31	₹111.55
50+	₹17.42	₹871.00
150+	₹15.33	₹2,299.50
500+	₹12.73	₹6,365.00
3,000+	₹11.56	₹34,680.00
6,000+	₹10.86	₹65,160.00

Quantity (min 5, multiples of 5)

5 × ₹22.31

₹111.55

excl. GST

₹131.63 incl. 18% GST

Need volume or a scheduled delivery? Request a quote

Dispatch in 7–10 working days
GST invoice with every order
Standard pack: 3,000 per reel

74HCT1G08GW-Q100,1

₹111.55 for 5 + GST

Specifications

Input Type: TTL-compatible CMOS
Logic Family: 74HCT
Voltage - Supply: 4.5V~5.5V
Propagation Delay: 11ns@4.5V,50pF
Output Logic Level - Low: 100mV;330mV
Features: Overvoltage-tolerant input
Input Logic Level - Low: 800mV
Operating Temperature: -40℃~+125℃
Input Logic Level - High: 2V
Output Logic Level - High: 4.4V~4.5V;4.13V~4.32V
Quiescent Current(Iq): 20uA
Current - Output High(IOH): 2mA
Number of Channels: 1;2
Current - Output Low(IOL): 2mA

Packaging & compliance

RoHS: ROHS3 Compliant
Lifecycle: Active
ECCN: EAR99
Packaging: Tape & Reel (TR)
Standard pack: 3,000 / Reel
Sold per: Piece
Minimum order: 5 (multiples of 5)
Unit weight: 0.09 g

Overview

The 74HC1G08-Q100; 74HCT1G08-Q100 is a single 2-input AND gate. Inputs include clamp diodes. This enables the use of current limiting resistors to interface inputs to voltages in excess of VCC. This product has been qualified to the Automotive Electronics Council (AEC) standard Q100 (Grade 1) and is suitable for use in automotive applications.

Key features

Automotive product qualification in accordance with AEC-Q100 (Grade 1)
Specified from -40 ℃ to +85 ℃ and from -40 ℃ to +125 ℃
Wide supply voltage range from 2.0 V to 6.0 V
CMOS low power dissipation
High noise immunity
Symmetrical output impedance
Balanced propagation delays
Latch-up performance exceeds 100 mA per JESD 78 Class II Level B
Input levels: For 74HC1G08-Q100: CMOS level For 74HCT1G08-Q100: TTL level
Complies with JEDEC standards: JESD8C (2.7 V to 3.6 V) JESD7A (2.0V to 6.0 V)
ESD protection: HBM: ANSI/ESDA/JEDEC JS-001 class 2 exceeds 2000 V CDM: ANSI/ESDA/JEDEC JS-002 class C3 exceeds 1000 V
