JSMSEMIDatasheet (PDF)
74LVC1G125GW-JSM
1.65V~5.5V 1 1 6.3ns@3.3V,50pF SOT-353 Buffers, Drivers, Receivers, Transceivers RoHS
SOT-353ROHS CompliantActive
- Manufacturer
- JSMSEMI
- Manufacturer part #
- 74LVC1G125GW-JSM
- Store part #
- C53426836
- Package / case
- SOT-353
- Packaging
- Tape & Reel (TR)
Every Order Guarantee
100% Authentic · 30-Day Return or Replacement · policy
2,820 in stock
#C53426836
Stock & price checked 45 h ago
| Quantity | Unit price | Pack price |
|---|---|---|
| 10+ | ₹6.40 | ₹64.00 |
| 100+ | ₹5.09 | ₹509.00 |
| 300+ | ₹4.43 | ₹1,329.00 |
| 3,000+ | ₹3.94 | ₹11,820.00 |
| 6,000+ | ₹3.56 | ₹21,360.00 |
| 9,000+ | ₹3.36 | ₹30,240.00 |
10 × ₹6.40
₹64.00
excl. GST
₹75.52 incl. 18% GST
- Dispatch in 7–10 working days
- GST invoice with every order
- Standard pack: 3,000 per reel
74LVC1G125GW-JSM
₹64.00 for 10 + GST
Specifications
- Current - Output High(IOH)
- 24mA
- Series
- 74LVC
- Voltage - Supply
- 1.65V~5.5V
- Output Type
- Tri-State
- Current - Output Low(IOL)
- 24mA
- Number of Bits per Element
- 1
- Channel Type
- Unidirectional
- Number of Elements
- 1
- Operating Temperature
- -40℃~+125℃
- Quiescent Supply Current
- 4uA
- Propagation Delay
- 6.3ns@3.3V,50pF
Packaging & compliance
- RoHS
- ROHS Compliant
- Lifecycle
- Active
- Packaging
- Tape & Reel (TR)
- Standard pack
- 3,000 / Reel
- Sold per
- Piece
- Minimum order
- 10 (multiples of 10)
- Unit weight
- 0.033 g
Overview
The 74LVC1G125 is a single buffer/line driver with 3-state output. The 3-state output is controlled by the output enable input (OE); when OE is driven HIGH, the output enters a high-impedance state. The inputs are compatible with 3.3V or 5V logic levels, allowing the device to be used in mixed 3.3V/5V voltage environments.
Key features
- Supply voltage range: 1.65V ~ 5.5V
- ±24 mA output drive (VCC = 3.0V)
- CMOS low power consumption
- Operating temperature range: -40°C ~ +125°C
- Package: SOT-23-5/SOT-353
